High chrome casting grinding round steel cylpebs for ball mill
High chrome casting grinding round steel cylpebs for ball mill
- Products introduction
Casting steel cylpeb has same production process and chemical composition with the casting steel ball, just the mould is different. It’s also divided into low, medium and high chrome. Mainly used in cement plants, mines and autoclaved aerated concrete block industry.
- Advantages
1.low breakage rate
2.low loss roundness rate
3.good quality
4.low wear-reisting
5.high hardness
6. ISO:901-2015 certification
- Size of casting steel cylpeb
| Dia*Length(mm) | Dia*Length(mm) | Dia*Length(mm) | Dia*Length(mm) |
| 10*10(12) | 12*12(14) | 14*14(16) | 16*16(18) |
| 18*18(20) | 20*25 | 25*30 | 30*35 |
| 35*40 | 40*45 | 45*50 | 50*55 |
- Chemical composition of casting steel cylpeb
|
| C(%) | Si(%) | Mn(%) | Cr(%) | Cu(%) | Mo(%) | P(%) | S(%) |
| Low Chrome | 2.1-3.6 | ≤1.5 | 0.3-1.5 | 1.0-3.0 | ≤0.80 | ≤1.0 | ≤0.10 | ≤0.10 |
| Medium Chrome | 2.1-3.6 | ≤1.5 | 0.3-1.5 | 4.0-6.0 | ≤0.80 | ≤1.0 | ≤0.10 | ≤0.10 |
| High Chrome | 2.0-3.3 | ≤1.2 | 0.3-1.5 | 10.0-24.0 | ≤0.80 | ≤1.0 | ≤0.10 | ≤0.10 |
- Performance of the steel cylpeb
|
| Hardness | Microstructure | Falling number | Impact value |
| Low Chrome | 45-50HRC | P+C(P-Pearlite C-Carbide) | ≥8000times | ≥1J/CM^2 |
| Medium Chrome | 48-53HRC | M+C(C-Carbide M-Martensite ) | ≥1000times | ≥2J/CM^2 |
| High Chrome | Windy quenching: 53-58HRC Oil quenching: 58-65HRC |
M+C(C-Carbide M-Martensite ) | ≥12000times | ≥3.5J/CM^2 |
- Company Profile
We, Jinan Huafu Forging Co., Ltd, mainly produces grinding media in ball mill for many years. With the strength of forged steel ball, cast steel ball, grinding rod, steel cylpeb and steel ball production equipment. All of our products are strictly according to the ISO9001-2008 Standard. We also have other company named Shandong Huafu Steel Ball Co., Ltd, so we have ability to produce high quality and large quantity products.
The products we can produced as follow:
Hot rolling steel ball:20-60mm
Forged steel ball: Dia. 60mm-150mm
Casting steel ball: Dia. 17mm-130mm
Grinding rod: Dia. 30mm-130mm. Length: 3m-9m
Casting steel cylpeb: 8mm*10mm-70mm*75mm
Hot Rolling Steel Cylpeb: 20*30mm-50*60mm
Steel ball production line: Dia.20-150mm
Ball Mill Liners: according to ball mill
Quality Inspections
Dimension inspection---Chemical inspection---Hardness inspection---Package inspection
- Production Process
Iron---Add Alloyed Material---Furnace Heating---Pouring to the Model---Out of the Model---Finishing---Quenching---Cooling---Tempering---Finished Products Testing---Packaging
- Application
Huafu Products are in wide application. Mainly used in mines, cement plant, power plant and chemical plant. The feedback from all of our customers are perfect.
- Packaging and Shipment
1).Bags:One bag=one ton
2).Steel drums
20mm-40mm:1000-900kg/drum.
50mm-120mm:850kg/drum
30mm-160mm: 800kg/drum
weight size volume
Bag 1kg 73*60cm 0.244m³
Iron Drum 10-13kg 55*88cm 0.23m³
Our Customer from All Over the World
Huafu Culture
The most honest and excellent partnering with Huafu
Our tenet:Credit first,standard operation,quality guaranteed,double win.
Our mission:Forge famous brand and high technology enterprise of China,produce high quality products favoured by home and aboard.
Our spirit:Pioneering,innovation,develop based on the market;high quality,high efficiency,serve our customer with full heart.
Our core value:Practical,forge ahead,customer first,quality excellence.
