Huafu 20-40mm hot rolling steel ball production line
Huafu 20-40mm hot rolling steel ball production line
(1)Our Company and Products:
We, Jinan Huafu Forging Co., Ltd, mainly produce grinding media for many years, with the strength of forged steel ball, cast steel ball, grinding rod and steel cylpeb. And all of our products strictly according to the ISO9001-2008 Quality Standard. The products model we can produced as follow:
Forged steel ball: Dia. 20mm-150mm
Cast steel ball: Dia. 17mm-130mm
Grinding rod: Dia. 30mm-130mm. Length: 3m-9m
Steel cylpeb: 8mm*10mm-70mm*75mm
(2)Medium-frequency induction furnace and heating beat
| Work piece diameter | Work piece weight KG | Production efficiency (piece/minute) | (KW) Electric power needed (KW) |
| Ø40mm | 0.2624 | 40-60 | 1000 |
| Ø60mm | 0.8856 | 40-60 | 1000 |
According to above calculation get the chart, for different weight, the same power supply power, calculate
different product time interval. Your esteemed company can choose suitable power as above mentioned ,
We advise you choose a little large power supply , so it can improve production efficiency highly, which
can adjust output power of power supply in production process, and choose the suitable time interval.
(3)Equipment mechanical system working process
Manual put material into storage rack→automatic continued feeding device→stokehole pinch roll feeding
device→furnace heating→pinch roll discharging speediness discharging→enter into rolling ball machine
→rolling ball quenching system→steel ball sweltering self tempering device→finished product steel ball
(4)Parts and Detailes
|
Sn. | Item | Type | Unit | Qty. | Total price (USD/set) FOB Qingdao |
| Ø40- Ø60 steel ball hot-rolling main equipments | |||||
| 1 | Power cabinet | 1000KW | set | 1 |
USD/set 550000-750000 |
| 2 | Furnace frame (including capacitor bank, aquage, circuit) | 1000KW | set | 1 | |
| 3 | Inductor | Ø40-Φ60 | set | 1 | |
| 4 | Connecting lead/copper bar (power supply to furnace body) | 1000KW | set | 1 | |
| 5 | Compression roller feeder |
| set | 1 | |
| 6 | Discharge frame and automatic continued feeding device |
| set | 1 | |
| 7 | 60-type rolling mill |
| set | 1 | |
| 8 | Steel ball roller | 40 | set | 1 | |
| 60 | set | 1 | |||
| 9 | Reduction box |
| set | 1 | |
| 10 | Drive motor for rolling |
| set | 1 | |
| 11 | Rolling mill reduction box link actuating arm |
| pcs | 1 | |
| 12 | Intelligent full-automatic control console |
| set | 1 | |
| 13 | Heat treatment quenching system |
| set | 1 | |
| 14 | Closed cooling machine |
| set | 1 |
|
| 15 | Other spare parts | ||||
(5)Packaging and Shipping:Wooden Cases
(6)Our Clients from Over the World
(7)How to contact us?
| Add: | Huamin industrial zone, Guanzhuang town, Zhangqiu city, Shandong province, China |
| Website: | www.jnhuafu.cn |
| Tel: | 0086-531-80957227 |
| Fax: | 0086-531-83807899 |
| MP/Whatsapp: | 0086-18577864569 |
| Wechat: | FXH0911 |
| QQ: | 2382023886 |
Welcome to send your detailed inquiry to my email
