40mm-80mm skew rolling mill for steel ball
40mm-80mm skew rolling mill for steel ball
Our Address: Zhangqiu city,Shandong province
Our company area:80000square meters area
Our employees:over 100
Annual production capacity:100000 tons
Registered capital:50 million yuan.
Main products:forged steel ball,casting iron ball,steel cylpebs ,grinding rod,mill liners,steel,hammerhead,automatic production line of steel ball &grinding rod and decorative wrought iron products.
1. Medium-frequency induction furnace and heating beat
Work piece diameter | Work piece weight KG | Production efficiency (piece/minute) | (KW) Electric power needed (KW) |
Ø40mm | 0.2624 | 40-60 | 1000 |
Ø60mm | 0.8856 | 40-60 | 1000 |
According to above calculation get the chart, for different weight, the same power supply power, calculate
different product time interval. Your esteemed company can choose suitable power as above mentioned ,
We advise you choose a little large power supply , so it can improve production efficiency highly, which
can adjust output power of power supply in production process, and choose the suitable time interval.
2.Equipment mechanical system working process
Manual put material into storage rack→automatic continued feeding device→stokehole pinch roll feeding
device→furnace heating→pinch roll discharging speediness discharging→enter into rolling ball machine
→rolling ball quenching system→steel ball sweltering self tempering device→finished product steel ball
3.
Sn. | Item | Type | Unit | Qty. |
|
Ø40- Ø60 steel ball hot-rolling main equipments | |||||
1 | Power cabinet | 1000KW |
set | 1 |
|
2 | Furnace frame (including capacitor bank, aquage, circuit) | 1000KW |
set | 1 | |
3 | Inductor | Ø40-Φ60 |
set | 1 | |
4 | Connecting lead/copper bar (power supply to furnace body) | 1000KW |
Set | 1 | |
5 | Compression roller feeder |
|
Set | 1 | |
6 |
Discharge frame and automatic continued feeding device |
|
Set | 1 | |
7 | 60-type rolling mill |
|
Set | 1 | |
8 | Steel ball roller | 40 |
Set | 1 | |
60 |
Set | 1 | |||
9 | Reduction box |
|
Set | 1 | |
10 | Drive motor for rolling |
|
Set | 1 | |
11 | Rolling mill reduction box link actuating arm |
|
Pcs | 1 | |
12 | Intelligent full-automatic control console |
|
Set | 1 | |
13 | Heat treatment quenching system |
|
set | 1 | |
14 | Closed cooling machine |
|
Set | 1 |
|
15 | Other spare parts | Please see the attachment:spare parts list | |||
Production process of Forged steel ball
1)Fully automatic production line of hot rolling steel ball
Manual put material into storage rack→automatic continued feeding device→stokehole pinch roll feeding device→furnace heating→pinch roll discharging speediness discharging→enter into rolling ball machine→rolling ball quenching system→steel ball sweltering self tempering device→finished product steel ball
2)Semi automatic production line of hot forging steel ball
Cutting raw material→furnace heating→forging→enter into rolling ball machine→Isothermal system→quenching system→steel ball sweltering self tempering device→finished product steel ball
3)Traditional production line of forged steel ball
Cutting raw material→furnace heating→forging→Isothermal system→quenching system→steel ball sweltering self tempering device→finished product steel ball
