Surface mounting Magnetic Proximity switch PS-S5020M applied in automation control or alarm system
Model NO. PS-S5020M Installation Surface mounting Pull-in Value 10-13AT Switching Type NO ( SPST ) Material ZINC-ALLOYED Working Temperature -20~80℃ Wire Gauge 1007 24AWG Wire Length 300mm Switching Voltage 200 VDC Switching Current 0.5A Contact life >100000 times
1.Magnetic Proximity switch is widely used in automation control, alarm system, output ON/OFF signal depending on the position of equipment.
2.Surface switch can be mounted with screws or double side tape , flush switch can be mounted in hole to keep covert.
NO&NC: 3 wires output, both with NO&NC
