Surface mounting Magnetic Proximity switch PS-S6618 applied in automation control or alarm system
Price:
Negotiable
MOQ:
100PCS
Delivery Time:
3-5 days
Brand:
JSUS
Product Description
Model NO. PS-S6618 Installation Surface mounting Pull-in Value 10-13AT Switching Type NO ( SPST ) Material ABS Working Temperature -20~80℃ Wire Gauge 2464 24AWG Wire Length 300mm Switching Voltage 200 VDC Switching Current 0.5A Contact life >100000 times
1.Magnetic Proximity switch is widely used in automation control, alarm system, output ON/OFF signal depending on the position of equipment.
2.Surface switch can be mounted with screws or double side tape , flush switch can be mounted in hole to keep covert.
3.Switching type definition:
NO: Normally open, switch ON when magnet nearly
NC: Normally close,switch OFF when magnet nearly
NO&NC: 3 wires output, both with NO&NC
NO&NC: 3 wires output, both with NO&NC
