Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine
dB5060 cutting die etching machine
dB5060 Flexible Magnetic Dies Etching Machine
DB5060 Photo Etching Machine for flexible dies
DB5060 Steel Flexible Dies Etching Machine
Making Process: Dry film photoresist & ink --- expose --- developer --- etching -- stripper --- cleaning --- drying --- CNC engraving ---- nickel & chrome plating --- finished
Introduction:
1. Flexible Dies Etching machine is a photoengraving machines for steel or high-carbon steel plate mold pretreating etching to advance following engraving processing.
2. After etching, the cutting knife-edge and knife depth is etched out.
3. Then the following CNC engraving Knife sharpening works is easy and fast.
4. It can save lots of unnecessary cost compare to use CNC engraving to working completely.
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
![Db5060 Rotary Flexible Dies Making Machine / Magnetic Dies Etching Machine]()
dB5060 cutting die etching machine
dB5060 Flexible Magnetic Dies Etching Machine
DB5060 Photo Etching Machine for flexible dies
DB5060 Steel Flexible Dies Etching Machine
| Power: | 7.5KW/380V |
| Working Size: | 500*600mm |
| Etching type: | Vertical spraying |
| Working Temp: | 40~55 degrees |
| Heat System: | Titanium, 3KW |
| Cool System: | Titanium Pipe |
| Motor power: | 4KW/380V |
| Machine Size: | 1950*1350*1550mm |
| Weight About; | 550kgs |
Control system: Temperature, Speed, Pressure, Network Filter
Making Process: Dry film photoresist & ink --- expose --- developer --- etching -- stripper --- cleaning --- drying --- CNC engraving ---- nickel & chrome plating --- finished
Introduction:
1. Flexible Dies Etching machine is a photoengraving machines for steel or high-carbon steel plate mold pretreating etching to advance following engraving processing.
2. After etching, the cutting knife-edge and knife depth is etched out.
3. Then the following CNC engraving Knife sharpening works is easy and fast.
4. It can save lots of unnecessary cost compare to use CNC engraving to working completely.
