190 Series Gas Engines and Generator Set for 11800KG Load Cutting-Edge Technology
Price:
10-1000
MOQ:
1
Delivery Time:
15 days
Product Description
| Main specification for gas gesets | |||||||
| Model of genset | Model of engine | Rated Power(KW/KVA) | Rated Voltage(V) | Rated Frequency(HZ) | Overall Dimension L*B*H(mm) | Net weigh(KG) | Fuel |
| 75GFZ-T | 4190T1-2 | 75/93.75 | 400/230 | 50 | 3766*1560*1737 | 5300 | natural gas |
| 125GFZ-T | 4190ZLT1-2 | 125/156.25 | 400/230 | 50 | 4106*1900*1896 | 7500 | natural gas |
| 210GFT-T | 6190ZLT-2 | 210/262.5 | 400/230 | 50 | 5105*2006*2110 | 8690 | natural gas |
| 250GF-TK | 6190ZLT-2 | 250/312.5 | 400/230 | 50 | 4935*1760*2441 | 8690 | natural gas |
| 400GF-NK | 12V190Z-2 | 400/500 | 400/230 | 50 | 5120*2200*2312 | 11300 | biogas |
| 400GF-T | 12V190DT2-2 | 400/500 | 400/230 | 50 | 6470*2110*2195 | 11800 | natural gas |
| 400GF-TK | 12V190DT2-2 | 400/500 | 400/230 | 50 | 4566*2040*2195 | 11300 | natural gas |
| 450GF1-NK | 12V190ZLDZ-2 | 450/562.5 | 400/230 | 50 | 5120*2200*2312 | 11300 | biogas |
| 500GF18-TK | 12V190ZDT-2 | 500/625 | 400/230 | 50 | 4566*2040*2780 | 11800 | natural gas |
| Main specification for gas engines | |||||||
| Model | Rated Power(KW) | Rated Speed(r/min) | Compression ratio | No.and layout of cylinders | Overall Dimension L*B*H(mm) | Net weigh(KG) | Fuel |
| 4190T1-2 | 110 | 1000 | 9:01 | 4 in line | 2405*1442*1645 | 3000 | natural gas |
| 4190ZLT1-2 | 165 | 1000 | 10:01 | 4 in line | 3560*1525*1730 | 3000 | biogas |
| 6190ZLT-2 | 270 | 1000 | 8:01 | 6 in line | 2990*1725*1801 | 3960 | natural gas |
| 12V190DT2-2 | 450 | 1000 | 9:01 | 12,60.Vee | 2670*1588*1898 | 5300 | natural gas |
| 12V190ZLDZ-2 | 500 | 1000 | 8:01 | 12,60.Vee | 2670*1588*2072 | 5300 | biogas |
| 12V190ZLDM-2 | 500 | 1000 | 8:01 | 12,60.Vee | 2670*1588*2072 | 5300 | coal gas |
| 12V190Z-2 | 500 | 1000 | 9:01 | 12,60.Vee | 2670*1588*1898 | 5300 | biogas |
| 12V190ZDT-2 | 550 | 1000 | 8:01 | 12,60.Vee | 2670*1588*2538 | 5300 | natural gas |
| Main technical data | |||||||
| Type:Four stroke,water cooled,turbocharged and aftercooled,spark plug ignition,outer mixing | |||||||
| Bore:190mm | |||||||
| Stroke:210mm | |||||||
| Direction of rotation:Counter-clockwise(facing to flywheel) | |||||||
| Starting method: electric motor | |||||||
| Lubricating method:Pressure and splash lubrication | |||||||
| Specific heat consumption:≤11386KJ/KW·h | |||||||
| Specific oil consumption:≤1.63g/KW·h | |||||||
| Stable speed regulating rate:0-5%adjustable | |||||||
Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
