China DX380 DX420 SWING REDUCTION GEAR 130426-00034 130426-00018 130426-00027A SWING REDUCER DX380 swing gearbox for sale

DX380 DX420 SWING REDUCTION GEAR 130426-00034 130426-00018 130426-00027A SWING REDUCER DX380 swing gearbox

Name: DX380 DX420 SWING REDUCTION GEAR 130426-00034 130426-00018 130426-00027A SWING REDUCER DX380 swing gearbox
Brand: Jiangmen Liba euipment Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Negotiable

Product Description

PRODUCT PARAMETERS

Part name	DX380 DX420 Swing gearbox
Equipment	Apply to DOOSAN EXCAVATOR
Part no.	130426-00034 130426-00018 130426-00027A
NO.1 sun gear spline teeth	20 splines
Swing pinion shaft teeth	14T
Item condition	New
Logo	LB
Gross weight	350 KG
MOQ	1 pc

Product Description

Pos.	Part No	Qty	Parts name	Comments
-.	130426-00034	[1]
-.	130426-00018	[1]		130426-00034
1.	130401-00066	[1]
10.	250201-01464	[1]
11.	120501-01875	[4]
12.	1.115-00232	[3]	RING;INNER
13.	131002-00305	[4]
14.	1.216-00017	[3]	CAGE,NEEDLE
15.	130413-00016	[4]
16.	130418-00314	[3]
17.	130425-00019	[1]
18.	130425-00045	[1]
18.	130425-00020	[1]		130425-00045
19.	120816-00086	[8]
2.	130712-00663	[1]
20.	120816-00085	[6]
21.	120816-00089	[1]
22.	250201-01465	[1]
23.	120705-00085	[11]
24.	110508-23737	[1]
24.	110508-07576	[1]
25.	2181-1116D3	[1]	PLUG;HEX. SOCKET
26.	2181-1116D1	[2]	PLUG
27.	800108-00095	[1]
29.	S5741380	[4]
3.	140107-00255	[1]
30.	120107-00138	[16]
31.	120107-00139	[1]
32.	120501-01877	[3]
33.	S0521456	[1]	BOLT M16X2.0X40
35.	420210-02138	[1]
35.	420210-02081	[1]
35.	420210-01120	[1]		420210-02081
35-1.	110910-00378	[1]
35-2.	2181-1110D10	[1]	ADAPTER
37.	S2221471	[4]	BOLT,SOCKET
4.	140105-00232	[1]
5.	401106-00203	[1]
51.	100502-00314	[1]
52.	100502-00313	[1]
6.	110508-07392	[1]
7.	130422-00043	[1]
8.	100502-00148	[1]
9.	100502-00149	[1]

Pos.	Part No	Qty	Parts name
-.	130426-00027	[1]
1.	130401-00127	[1]
10.	250201-01464	[1]
11.	120501-01875	[4]
12.	1.115-00232	[4]	RING;INNER
13.	131002-00305	[4]
14.	1.216-00017	[4]	CAGE,NEEDLE
15.	130413-00016	[4]
16.	130418-00404	[4]
17.	130425-00019	[1]
18.	130425-00031	[1]
19.	120816-00086	[8]
2.	130712-00663	[1]
20.	120816-00085	[8]
21.	120816-00089	[1]
22.	250201-01948	[1]
23.	120705-00085	[12]
24.	110508-07576	[1]
25.	2181-1116D3	[1]	PLUG;HEX. SOCKET
26.	2181-1116D1	[2]	PLUG
27.	800108-00095	[1]
29.	S5741380	[4]
3.	140107-00255	[1]
30.	120107-00138	[16]
31.	120107-00139	[1]
32.	120501-01877	[3]
33.	S0521456	[1]	BOLT M16X2.0X40
35.	420210-01120	[1]
35-1.	110910-00378	[1]
35-2.	2181-1110D10	[1]	ADAPTER
37.	S2221471	[4]	BOLT,SOCKET
4.	140105-00232	[1]
5.	401106-00203	[1]
6.	110508-07392	[1]
7.	130422-00043	[1]
8.	100502-00148	[1]
9.	100502-00190	[1]
