Glass Edging Machine for Straight Line Glass Polish Machine Glass Grinding Equipment
The machine is glass 9 motors straight line edging machine,, used for grinding and polishing the bottom edge and edge of flat glass. A special telescopic platen is used to grind glass of different thicknesses. The machine is easy to operate and stable. The front rails can be moved in parallel to adjust the thickness of the glass for easy and precise operation. The chamfering grinding wheel adopts pallet, and there is no vibration during grinding. The main transmission is frequency conversion speed regulation.
The special part is the input conveyor rack to be vertically adjustable up and down ,the function is to adjust the grinding amount by rotate the rotation handle ,and the grind amount digital display.
Wheels: 9 .
working speed: 0.6-6.0m/min
Max. arris width: 2.5mm
Min. glass size: 60mm
Glass thickness: 3-20mm
Total power: 18.75kw
Total dimension: 6.6x1.0x2.6m
Total weight: 2800kg
1.What other Tempering furnace Size do you have? We have size:1000*2000, 1200*2500, 1500*3000, 1830*2440, 2000*3000, 2440*3660, 3000*5000 etc.
2.Can the machine be customized on request?
Yes, we can make customized machine.
3.How about after-sales service?
We can dispatch engineers, provide remote installation instructions, and local technicians. We provide lifetime technical service.
4.Deliverty time?
30-90 days,depends on machine size.
5.What other machines do you have?
We also have Glass Edging mahcine,
Glass beveling machine
Glass cutting machine
Glass washing machine
Glass sandblating machine
Glass drilling machine
Glass laminating furnace
Etc
