Portable Cellular 4G Router wireless hotspot router

Chip platform Modem: ZX297520V3T,Wi-Fi: MT6631

Size 147*72*15mm

Weight about 270g(Led)/ 280g(LCD)

Product form 4G Portable Mobile WiFi

Frequency band

(Optional) SKU1:4G:FDD B1/B3/B7/B8/B20; 3G:WCDMA B1/B8, (TDD Optional)

SKU2:4G:FDD B2/B4/B5/B7,WCDMA B2/B4/B5

SKU3:4G:FDD B1/B3/B8,TDD B34/B39/B40/B41, 3G:B1/B8

SKU4:4G:FDD B1/B3/B5; 3G:WCDMA B1

(*More Frequency band can be customized. )

4G Max. Transmit Power 23 ±2dBm (Power Class 3)

Hardware interface 2*nano SIM(4FF), 1* ESIM (5x6 patch card-built in optional), 1*Power button, 1*Menu button,  1*USB Type-C,  1*Emergency shutdown key

LED 4G/3G signal, Online, WiFi signal, Power,  Power charge,   (optional 2 "TFT screen),

4G/3G rate 4G(LTE):DL up to 150Mbps/UL up to 50Mbps;

3G(WCDMA):DL up to 21.6Mbps/UL up to 5.76Mbps.

Cellular antenna Built in, 2x2 MIMO

Wi-Fi protocol 2.4GHz & 5.8GHz,   802.11 b/g/n/ac.

Wi-Fi rate 802.11ax  up to 433Mbps (2.4GHz 150Mbps, 5.8GHz 433Mbps.)

Wi Fi antenna Built-in  1x1  MIMO

Browser Microsoft Edge, Google Chrome (Win), Firefox, Safari,  Opera

Battery 3.8V Li-ion 8000mAh,Non-removable

Maximum number of access users 10

Reliability Operating temperature: -10℃ to +40º C,  Storage temperature: -10ºC to 50ºC,

Operating humidity: 10% to 95%,   Storage humidity: 5% to 95%.
