Classic Hinged Casement Aluminium Window Weather Resistance Custom Casement Windows
80 Series Casement Window: Classic Hinged Design with Enhanced Durability and Weather Resistance
INFORMATION
| Brand | Dimax |
| Material | 6063-T5 |
| Thickness | 2.0mm |
| Bearing | 80kg |
| Blade width | 600-900mm |
| Blade height | 600-1800mm |
| Certification | NFRC, CSA, CE, |
| Glass | Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass |
| Powder-coat | Interpon, Dulux (warranty treatment 10/20 years) |
| Hardware | KIN LONG,BONWAY,ROTO and so on |
| Configuration | A. AA. A/F or customized design |
| Heat Insulation | UW1.2W/㎡K |
| soundlnsulafion | Rw up to 37dB |
| Ufimate Wind Pressure | +5040pa |
| Water Resistance | +720Pa |
The 80 Series Casement Window delivers superior ventilation control and weathertight security through its mechanically-vented hinge system and compression-sealed frame design. Engineered for architectural versatility, it features slim-profile sightlines that enhance views while maintaining structural rigidity under wind loads. The thermally-optimized chambered construction reduces energy transfer, supporting sustainable building standards without compromising on its classic outward-opening operation. Customizable with reinforced locking points, laminated glazing options, and corrosion-resistant finishes, this series meets rigorous performance demands for coastal residences, urban environments, and commercial projects where durability meets design precision.
