Premium Aluminium Window And Door Multi Panel Aluminum Sliding Glass Doors
80 Series Roto Patio Alversa Sliding Door: Premium Multi-Panel Design for Seamless Outdoor Living
INFORMATION
| Brand | Dimax |
| Material | 6063-T5 |
| Thickness | 2.0mm |
| Bearing | 200kg |
| Blade width | 600-1300mm |
| Blade height | 1000-3000mm |
| Certification | NFRC, CSA, CE, |
| Glass | Single-pane glass, laminated glass, double-layer tempered glass, tempered laminated glass, triple-layer tempered glass |
| Powder-coat | Interpon, Dulux (warranty treatment 10/20 years) |
| Hardware | ROTO |
| Configuration | XXO,OXX,OXXXXO,corner slider or customized design |
| Heat Insulation | UW1.0W/㎡K |
| soundlnsulafion | Rw up to 35dB |
| Ufimate Wind Pressure | +5000pa |
| Water Resistance | +72Pa |
The 80 Series Roto Patio Alversa Sliding Door features a multi-panel folding opening system that enables seamless indoor-outdoor transition and unobstructed panoramic views. Its patented load-bearing track and reinforced roller mechanism support flexible configurations of up to 12 panels, with each panel capable of carrying up to 300 kg while maintaining quiet and smooth sliding operation. The door system utilizes triple-glazed insulating glass combined with thermally broken profiles through low-temperature welding, achieving a U-value as low as 1.0 W/(m²·K). Enhanced by adjustable compression seals, it delivers breakthrough performance in both air and water tightness. The system incorporates concealed drainage channels and anti-uplift locking devices to meet extreme climate protection requirements in coastal and high-wind regions. Surface finishes include anodizing, wood-grain transfer printing, and dual-color co-extrusion processes, ensuring aesthetic integration with modern architectural facades.
