DIN17175 St35.8 St45.8 1-20mm Thick Wall Steel Pipe Seamless Carbon Steel
Price:
Negotiable
MOQ:
1
Delivery Time:
7~30 working days
Brand:
BaoYang
Product Description
| Parameter | Description |
|---|---|
| Grades | DIN 17175 St35.8 and St45.8 |
| Material | Carbon Steel (Seamless) |
| Standard | DIN 17175 |
| Wall Thickness | Thick wall as per customer requirements and application needs |
| Size Range | Various diameters and wall thicknesses |
| Length | Standard lengths, customizable upon request |
| Ends | Plain ends, beveled ends, threaded, or socket-weld ends |
| Surface Treatment | As-rolled, annealed, or normalized |
- Seamless Construction: Offers superior pressure resistance and eliminates potential seam failures.
- High Yield Strength: St35.8 and St45.8 indicate the minimum yield strength, providing reliable mechanical properties.
- Customizable Wall Thickness: Available in various wall thicknesses to suit different pressure requirements.
- Long Service Life: Designed for longevity in demanding environments.
- Corrosion Resistance: Offers inherent resistance to many corrosive agents.
- Pressure Vessels: Ideal for use in the construction of pressure vessels and high-pressure boilers.
- Oil and Gas Industry: Used for pipelines and equipment in the oil and gas sector.
- Chemical Processing: Suitable for handling corrosive chemicals in the chemical industry.
- Power Plants: Employed in steam lines and other high-temperature, high-pressure systems.
- Structural Applications: Utilized in structural applications requiring thick-walled pipes.
- DIN 17175: The pipes are manufactured in compliance with the German Industrial Standard (DIN) 17175, ensuring quality and reliability.
| Property | DIN 17175 St35.8 | DIN 17175 St45.8 |
|---|---|---|
| Tensile Strength | ≥510 MPa (74,500 psi) | ≥590 MPa (85,500 psi) |
| Yield Strength | ≥335 MPa (48,600 psi) | ≥435 MPa (63,200 psi) |
| Elongation | ≥18% in 50 mm (2 in) | ≥18% in 50 mm (2 in) |
| Hardness | Typically Rockwell B 90 max |
| Element | DIN 17175 St35.8 Range (%) | DIN 17175 St45.8 Range (%) |
|---|---|---|
| Carbon | 0.10 - 0.20 | 0.12 - 0.20 |
| Manganese | Up to 1.00 | Up to 1.00 |
| Phosphorus | ≤ 0.035 | ≤ 0.035 |
| Sulfur | ≤ 0.035 | ≤ 0.035 |
| Silicon | Up to 0.50 | Up to 0.50 |
