Kubota Engine 3.5 Ton Vibrating Road Roller for Industrial Earthwork Construction
Price:
$8,500.00/sets 1-9 sets
MOQ:
1 unit
Delivery Time:
Negotiable
Brand:
HUAQI
Product Description
Brand New 3.5 Ton Vibrating Road Roller Hydraulic Compactor Road Building Industrial Earthwork Machinery For Sale
The Single Steel Wheel Paver Roller is a sturdy and high-performing compaction machine designed for a wide range of road construction and compaction tasks. It is available with either a reliable Changchai or Changfa 390 engine, providing an impressive power output of 39 horsepower, ensuring exceptional performance and efficiency. Operating at speeds ranging from 2 to 8 km/h, the offers versatility and excellent maneuverability on various terrains. With an outstanding climbing ability of 40%, it can handle steep inclines and challenging working environments with ease. The paver roller is equipped with a nominal amplitude of 0.6 mm and operates at a vibration frequency of 45 Hz, delivering effective and consistent compaction results. The powerful excitation force of 55 KN ensures optimal compaction efficiency, achieving superior density for different construction materials.
Discounted
Product Description
Specification
Parameter | Value | Parameter | Value |
Name | LS-3500 Single Steel Wheel Paver Roller | Engine Brand | Changchai/Changfa |
Travel Speed | 2-8 km/h (Forward/Reverse) | Engine Model | 390 |
Climbing Ability | 40% | Engine Power | 39 HP |
Nominal Amplitude | 0.6 mm | Vibration Frequency | 45 Hz |
Excitation Force | 55 KN | Static Linear Load | 90 N/cm |
Fuel Tank Capacity | 74 L | Hydraulic Oil Capacity | 74 L |
Vibration Mode | Hydraulic Vibration | Fuel Consumption Rate | ≤ 310 g/kWh |
Starting Method | Electric Start | Steel Wheel Width | 1200 mm |
Operating Weight | 3500 kg | Steel Wheel Diameter | 950 mm |
Water Tank Capacity | 200 L | Exterior Dimensions | 3830*1530*1920mm |
Company Profile
Product packaging
Certifications
FAQ
1.Q:Can the factory support mass production? Can i purchase a customized sample first? A:Dear friends, our company can support mass production. It can mass produce 200+Road roller in one month, can support customization, can customize colors and logos, etc. 2.Q:Can it be transported to my door? I want to get my favorite mini excavator soon? A:Of course, my friend, but if your family is located very close to the port, we suggest that you can go directly to the port to transport your goods, so you can save a lot of money! If the distance is long, you can find an inland transportation company by yourself, and we can communicate with him; we can also find an agency for you, but the toll will be very high (not recommended)during transportation, we will not charge any intermediate fees and additional service fees other than freight. We just want you to get your favorite Road roller earlier. 3.Q:How can i guarantee after-sales after i buy it? A:Dear friends, our machine has a one-year/1000h work warranty period. During this time, if there is any problem
