HONDA Powered 20KN Walk Behind Vibratory Mini Road Roller for Asphalt and Soil Pavement
550 kg walk behind vibratory mini road roller double drum road roller for asphalt and soil pavement
SPECIFICATION SHEET
| ITEM NO/DETAILS | HQ550 | ||
| ENGINE | |||
| Engine | CHANGCHAI 178 | HONDA GX270 | |
| Engine type | One cylinde, air-cooled, four-stroke, diesel | One cylinde, air-cooled, four-stroke, gasoline | |
| Number of cylinders | 1 | ||
| Output power (HP) | 6 | 9 | |
| Rating speed(RPM) | 3600 | 3600 | |
| Fuel consupmtion(G/KWH) | ≤280 | ||
| Lubricating oil volume(L) | 1.1 | 2 | |
| Start up | Hand recoild/Electric start | ||
| DRIVING | |||
| Electrical equipment(V) | 12 | ||
| Drive mode | Two-way hydraulic, chain drive | ||
| Walking speed (KM/H) | 0--4 | ||
| Theoretical climbing ability(%) | 30 | ||
| EXCITING SYSTEM | |||
| Vibration wheel | Front+rear | ||
| Drive form | Mechanical type | ||
| Vibration frequency (HZ) | 70 | ||
| Vibration amplitude (MM) | 0.5 | ||
| Exciting force(KN) | 20 | ||
| SPRINGKLING SYSTEM | |||
| Water spray form | Gravity-type water spray | ||
| CAPACITY | |||
| Fuel capacity(L) | 3.5 | 5.9 | |
| Hydraulic oil capacity(L) | 17 | ||
| Water tank capacity (L) | 13 | ||
| SIZE | |||
| Working width(MM) | 770 | ||
| Overall length(MM) | 2480 | ||
| Machine height(MM) | 1170 | ||
| Drum size | 425*600mm*2 | ||
| Drum thickness(MM) | 12 | ||
| Ground clearance(MM) | 170 | ||
| WEIGHT | |||
| Working weight(KG) | 550 | ||
| Static load(N/CM) | 45/50 | ||
Advices on Choosing A Vibratory Road Roller:
1. If the labor costs is high in your country, please kindly choose the ride on type road roller, more comfortable for workers.
2. If the degree of mechanization is not very high in your country, please kindly choose the walk behind type small compacting roller.
3. If you compact the wide road(like soil, asphalt, sand, concrete and lawn), please consider the compaction effect you want to get, then choose a compactor roller of corresponding weight. We have 330kg, 550kg, 800kg, 1000kg, 1200kg, 1500kg, 2000kg, 2500kg and 3000kg weight of road roller. The heavier the road roller is, the bigger the exciting force can be.
4. If you compact the narrow road(trench), please conside the width of the road(trench), the width of the road roller drum must smaller than the width of the road(trench). We have 600mm, 635mm, 700mm, 800mm, 900mm, 1000mm, 1100mm and 1200mm drum width of road roller.
