Corning H TypeField Assembly Reinforced Optical Fast Connectors For FTTH/FTTP Networks
Corning Optitap SC APC Waterproof Fast Connector Pre-terminated Reinforced Fiber optic connector
The OptiTap SC APC Field Installable Reinforced Waterproof Fiber Optic Connector is a versatile solution designed for outdoor fiber optic networks. Supporting a wide range of cable types, including flat and round drop cables, it is fully compatible with MST terminal boxes and Corning OptiTap systems. This waterproof and durable connector offers a robust design for reliable performance in extreme environmental conditions, making it the perfect choice for FTTA, broadband, and telecom applications. Its compact size, blind-mating mechanism, and ease of installation make it ideal for both new installations and quick field repairs.
Specification:
| Item | Specification |
| Cable Type | 2×3.0mm, 2×5.0mm flat; round 3.0mm, 2.0mm |
| End face performance | Conform to YD T 2341.1-2011 |
| Insertion Loss | ≤0. 0dB |
| Return Loss | ≥55.0dB |
| Mechanical Durability | 1000 cycles |
| 2.0x3.0mm (Ttap Fast Connector) | ≥30N; 2Minute |
| 2.0x3.0mm (Ttap Connector) | ≥30N; 2Minute |
| 5.0mm (Ttap Connector) | ≥70N; 2Minute |
| Torsion of optical cable | ≥15N |
| Drop performance | 10 drops under 1.5m height |
| Application Time | ~30 seconds (excluding fiber presetting) |
| working environment | under 90% relative humidity ,70°C |
Feature:
1.1 Waterproof and Dustproof: The OptiTap connector includes a robust sealing system that protects the fiber connection from water, dust, and other environmental contaminants, meeting IP68 standards.
2.2 Telecom Networks: Ideal for MST terminal boxes and outdoor SC ports.
2.3 Broadband Networks: Provides fast and waterproof connections for FTTP and FTTX projects.
2.4 Data Transmission Networks: Maintains high-speed connectivity in harsh environments.
2.5 Outdoor Cable Repairs: The best solution for quick field fixes without the need for pre-terminated connectors.
