Customized and Lightweight 2 kg HYDWELL PP Melt Blown Filter Element for Filtration
Price:
$1.00 - $19.80/pieces
MOQ:
100 pieces
Delivery Time:
Negotiable
Brand:
hydwell
Product Description
Specifications | ||||||||||||
Materials Of Construction | Filter Media: | Polypropylene | ||||||||||
Support Layers: | Polypropylene | |||||||||||
Micron Rating: | 0.1, 0.2, 0.45, 0.65, 1.0, 3.0, 5.0um | |||||||||||
Inner core: | Polypropylene | |||||||||||
Outer Cage, End caps: | Polypropylene | |||||||||||
Seal Method: | Thermal Bonded, No Adhesives | |||||||||||
O-rings/gaskets: | Silicone, Nitrile, EPDM, Viton, , etc | |||||||||||
Cartridge Dimensions | Outer Diameter | 69mm(2.75'') | ||||||||||
Inner Diameter | 33mm(1.30'') | |||||||||||
Length(based on DOE end caps) | 10"- 254mm, 20"- 508mm, 30"-762 mm, 40"- 1016mm | |||||||||||
Filtration Area(m2) | 0.65 m2 per 10'' | |||||||||||
Operating conditions | Normal Operating Temperature: | Up to 60℃ (140℉) | ||||||||||
Max.Operating Temperature: | 80℃ (172℉) at P≤1.0 bar (14psi) | |||||||||||
Max. Differential Pressure | ||||||||||||
Normal Flow direction: | 4.2 bar (60 psi) at 25℃ (77℉) | |||||||||||
Reverse flow direction: | 2.1 bar (30psi) at 25℃ (77℉). | |||||||||||
PH Value compatibility: | 1-13 | |||||||||||
Sterilization: | Steam Sterilization for 30 minutes at 121±2 ℃, | |||||||||||
Cumulative Time:15hours; | ||||||||||||
Flush with hot water at 82℃(180℉) for 30 minutes, | ||||||||||||
at P≤1.0 bar (14psi) -- Recommended. | ||||||||||||
Cartridge Safety | Endotoxin: | <0.25 EU/ml | ||||||||||
Extractables: | 0.03g / 10" | |||||||||||
FAQ
Q1: Can you accept the sample order? Yes, we can.
Q2: Could I put my logo on it?
Of course. The logo can be made according to your requirements once you reached our MOQ.
Q3: What's your packaging?
Neutral package. Welcome to customized if you need.
Q4: What's your lead time?
3-7 days for the sample orders in the stock. 25-30 days for the mass production.
Q5: Are you a factory?
We are not just factories, we have more than 10 years of R&D capabilities.
