Commercial/Industrial Air Cooler Condenser with 380V/220V Voltage and Direct Drive Motor Type
Product Description:
The Air Cooler Condenser is equipped with a direct drive motor, which provides a high level of efficiency and durability. This motor is specially designed to operate at optimal performance levels, ensuring that the condenser is able to maintain consistent cooling temperatures even under heavy use. Additionally, the motor is available in both 380V and 220V voltage options, making it ideal for a range of different applications and environments.
The H-Type Air Cooled Condenser is another popular option, offering a high level of efficiency and performance in a compact and easy-to-install package. This condenser is designed to be highly durable and long-lasting, even in demanding industrial environments. With its powerful cooling capabilities and versatile design, the H-Type Air Cooled Condenser is an excellent choice for a wide range of different cooling applications.
In conclusion, the Air Cooler Condenser is a highly effective and reliable cooling solution for commercial and industrial applications. With its air cooling method, direct drive motor, and range of different configurations and options, this condenser is able to provide consistent and efficient cooling in even the most demanding environments. Whether you need to cool a cold storage facility, a refrigeration system, or any other industrial application, the Air Cooler Condenser is an excellent choice that is sure to provide reliable and long-lasting performance.
Features:
- Product Name: Air Cooler Condenser
- Application: Commercial/Industrial
- Voltage: 380V/220V
- Origin: China
- Cooling Method: Air Cooling
- Number Of Fans: 2-6
- Keywords: Refrigeration Air Cooled Condenser, H-Type Air Cooled Condenser, Refrigeration Air Cooled Condenser
Technical Parameters:
| Area | Row bend several | Fan | Intake pipe Ømm | The liquid pipe Ømm | Weight kg | |||||
| Number | Power(W) | Air volume m³/h | Wind leaf diameter Ø mm | Voltage(V) | ||||||
| FNH-0.6/2 | 2 | 2x4.5 | 1 | 16 | 500 | 200 | 220 | 10 | 10 | 4 |
| FNH-0.9/3 | 3 | 3x45 | 1 | 16 | 500 | 200 | 220 | 10 | 10 | 43 |
| FNH-1.2/4 | 4 | 3x5.5 | 1 | 40 | 800 | 250 | 220 | 10 | 10 | 6 |
| FNH-1.8/6 | 6 | 3×7 | 1 | 90 | 1250 | 300 | 220 | 10 | 10 | 8 |
| FNH-2.5/8.5 | 8.5 | 4×7 | 1 | 90 | 1250 | 300 | 220 | 10 | 10 | 10.2 |
| FNH-3.6/12 | 12 | 4×8 | 1 | 164 | 1800 | 350 | 220/380 | 16 | 12 | 13.8 |
| FNH-4.5/15 | 15 | 4×9 | 1 | 164 | 1800 | 350 | 220/380 | 16 | 12 | 16.5 |
| FNH-5.4/18 | 18 | 4×10 | 1 | 216 | 3000 | 400 | 220/380 | 16 | 12 | 22 |
| FNH-6.6/22A | 22 | 5×10 | 1 | 216 | 3000 | 400 | 220/380 | 19 | 16 | 24 |
| FNH 7.6/22B | 22 | 4×8 | 2 | 2×164 | 2×1800 | 350 | 380 | 19 | 16 | 26 |
| FNH-8.4/28 | 28 | 4×8 | 2 | 2×164 | 2×1800 | 350 | 380 | 19 | 16 | 29 |
| FNH-9.9/33 | 33 | 4×9 | 2 | 2×216 | 2×3000 | 400 | 380 | 19 | 16 | 36 |
| FNH-13.0/41 | 41 | 4×12 | 2 | 2×216 | 2×3000 | 400 | 380 | 19 | 16 | 40 |
| FNH-15.0/49 | 49 | 4×14 | 2 | 2×216 | 2×3000 | 400 | 380 | 19 | 16 | 50 |
| FNH-18.0/60 | 60 | 4×14 | 2 | 2×216 | 2×3000 | 400 | 380 | 22 | 16 | 58 |
| FNH-21.0/70 | 70 | 4×18 | 4 | 4×164 | 4×1800 | 350 | 380 | 22 | 19 | 72 |
| FNH-24.0/80 | 80 | 4×20 | 4 | 4×216 | 4×1800 | 400 | 380 | 25 | 22 | 81 |
| FNH-27.0/90 | 90 | 4×20 | 4 | 4x216 | 4×3000 | 400 | 380 | 25 | 19 | 90 |
| FNH-30.0/100 | 100 | 4x24 | 4 | 4x216 | 4×3000 | 400 | 380 | 25 | 19 | 98 |
| FNH-36.0/120 | 120 | 4×24 | 4 | 4x216 | 4×3000 | 400 | 380 | 28 | 19 | 105 |
| FNH-42.0/140 | 140 | 5×24 | 4 | 4x290 | 4×4500 | 450 | 380 | 28 | 22 | 128 |
| FNH-45.0/150 | 150 | 5×24 | 4 | 4x290 | 4×4500 | 450 | 380 | 32 | 25 | 135 |
| FNH1-54.0/180 | 180 | 6x24 | 4 | 4x449 | 4x6500 | 500 | 380 | 32 | 25 | 170 |
| FNH-60.0/200 | 200 | 6×24 | 4 | 4x449 | 4x6500 | 500 | 380 | 32 | 25 | 190 |
| FNH-66.0/220 | 220 | 6x25 | 4 | 4x449 | 4x6500 | 500 | 380 | 32 | 25 | 200 |
| FNH-75.0/250 | 250 | 6x28 | 4 | 4x670 | 4×8500 | 550 | 380 | 32 | 25 | 220 |
| FNH-90.0/300 | 300 | 6x28 | 4 | 4x670 | 4×8500 | 550 | 380 | 32 | 25 | 260 |
Applications:
This air-cooled condenser is suitable for use in a variety of applications, including freezer room condensing units, steam condensers, and more. With its robust design and high-performance fans, it is capable of handling even the most demanding cooling requirements.
If you're looking for a reliable and efficient cooling solution for your commercial or industrial application, the Damai DM-FNU Air Cooler Condenser is an excellent choice. Its high-quality construction, robust design, and efficient cooling method make it one of the best options on the market today.
Order yours today and experience the benefits of a top-of-the-line air-cooled condenser for your business!
Support and Services:
The Air Cooler Condenser is a high-performance product designed to cool and condense air in various industrial and commercial applications. Our team of technical support experts and engineers are available to assist with any questions or issues you may have with the product.
We offer a range of services to ensure the optimal performance and longevity of your Air Cooler Condenser, including:
- Installation support and guidance
- Maintenance and repair services
- Performance testing and analysis
- Custom design and engineering solutions
Our technical support team is available to provide assistance via phone, email, or on-site visits as necessary. Contact us today to learn more about how we can help you get the most out of your Air Cooler Condenser.
FAQ:
Q: What is the brand name of this air cooler condenser?
A: The brand name is Damai.
Q: What is the minimum order quantity for this air cooler condenser?
A: The minimum order quantity is 1.
Q: What is the price range for this air cooler condenser?
A: The price range is between $200 and $100000.
Q: How is this air cooler condenser packaged for shipping?
A: It is packaged in a wooden case.
Q: What is the delivery time for this air cooler condenser?
A: The delivery time is 15 work days.
Q: What are the payment terms for this air cooler condenser?
A: The payment terms are T/T.
Q: What is the supply ability for this air cooler condenser?
A: The supply ability is 1000000pcs/year.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
