Brictec Pulverized Coal Burner with 12 Coal Feeding Points and 115kw Thermal Power for High-Efficiency Combustion
Price:
10000-13000 US$/SET
MOQ:
1
Delivery Time:
45 days
Brand:
BRICTEC
Product Description
Brictec Pulverized Coal Burner – High-Efficiency Combustion Solution
Equipment Introduction
The Xi'an Brictec PCS Series automatic pulverized coal firing system is a fully-automated production solution designed for the brick and tile industry. This integrated system combines raw coal metering, crushing, drying, feeding, burning, and monitoring functions to optimize continuous firing kilns that utilize top-fed pulverized coal combustion.
System Components
- Hardware: Raw coal storage silo, scale conveyor belt, coal crusher, screw conveyor, pulverized coal dryer, dust collector, chain feeder, and pulverized coal burner
- Software: Data acquisition unit, data analysis and processing unit, control unit, and feedback adjustment unit
Technical Specifications
| Number of coal feeding points | 12 |
|---|---|
| Power of screw conveyor | 0.37kW |
| Maximum flow at single feeding point | 180m³/h |
| Maximum thermal power at single feeding point | 115kw |
| Voltage | 380V |
| Auxiliary power supply | 24V |
| Operating temperature range | -10 to 50℃ |
Pulverized Coal Requirements
| Maximum particle size | ≤5 mm |
|---|---|
| Moisture content | ≤5% |
| Sulfur content | ≤4% |
| Hardgrove grindability index | ≥50 |
| Calorific value | ≥6000 cal |
Global Service Coverage
- Asia: China, Kazakhstan, Uzbekistan, Tajikistan, Turkmenistan, Vietnam, Malaysia, India, Bangladesh, Nepal, Pakistan
- Middle East: Iraq
- Europe: Russia, Kosovo
- Africa: South Africa, Morocco, Zimbabwe, Nigeria, Guinea
- South America: Peru, Colombia, Mexico, Brazil, Venezuela
Xi'an Brictec maintains local offices and after-sales service centers in Iraq, Kazakhstan, and Bangladesh. Committed to our "Customer Centric, Striving People-Oriented" philosophy, we provide comprehensive support to simplify your brick production processes.
