Metal Surface Powder Coating Production Line PT-S45-5 450g/min Electrostatic Sprayer
Price:
$1,400.00/pieces 1-10 pieces
MOQ:
1
Delivery Time:
Negotiable
Brand:
huaxiang
Product Description
Spraying Gun Paint 450g/min PT-S45-5 Powder Coating Electrostatic Sprayer Painting Equipment Machine Metal Coating Machinery 33
-
Vibratory Powder Feeding
- Utilizes a vibration mechanism to ensure uniform powder supply, facilitating smooth powder flow during the spraying process and reducing clogging.
-
Enhanced Electrostatic Attraction
- Combines electrostatic spraying technology with vibratory feeding to improve powder adhesion and coating uniformity, ensuring better coating results.
-
High Powder Utilization Rate
- The combination of electrostatic attraction and vibratory feeding leads to high powder utilization, minimizing material waste.
-
Wide Applicability
- Suitable for various shapes of workpieces, particularly complex and irregular surfaces, enabling efficient coating.
-
Ease of Operation
- Designed to be user-friendly, making it simple to operate and adjust spraying parameters.
-
Easy Cleaning and Maintenance
- The structure is designed for easy cleaning and maintenance, reducing downtime.
-
Versatility
- Capable of spraying various powder coatings, adapting to different coating needs.
-
Environmental Friendliness
- Compared to traditional spraying methods, it reduces harmful emissions, aligning with environmental standards.
|
Voltage
|
100~240VAC
|
|
Frenquency
|
50/60HZ
|
|
power
|
50W
|
|
Safety Level
|
IP54
|
|
Ambient Temperature
|
0-40°C
|
|
Input Air pressure
|
0.55MPa(5.5bar,80PSI)
|
|
Maximum powder injection
|
600g/min
|
|
Gun weight
|
480g
|
|
Maximum Output Voltage
|
120kv
|
|
Maximum Output Current
|
120µA
|
|
The length of Powder Tube
|
3.5meters
|
|
Accessories included in the machine
|
Quantity
|
|
Gun
|
1 SET
|
|
Controller
|
1 SET
|
|
Low Temperature Soft Powder Pipe
|
1 SET /3.5Meters
|
|
Vertical Powder Pump
|
1 SET
|
|
Stainless Steel Barrel
|
1 SET /40L-45L
|
|
Overflow Pipe
|
1 SET
|
|
Movable Trolley
|
1 SET
|
|
Oil and Water Separator
|
1 SET
|
|
Consumables
|
Some
|
|
Net weight of machine
|
40KG
|
|
package Size ,Weight
|
500mm(L)*500mm(W)*1020mm(H), 45-50KG
|
