Antimagnetic Winch Gearbox Gfw17t2 Gfw17t3 Gfw26t2 Gfw36t3 Gfw40t2 Gfw50t2 Gfw50t3 Gfw60t2
Price:
Negotiable
MOQ:
5
Delivery Time:
Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
Product Description
| MODEL | MAX OUTPUT TORQUE | RANGE OF RATIO | MAX. INPUT SPEED | ORBITAL HYD. MOTOR | HYDRAULIC PISTON MOTOR | INTERCHANGEABLE MODEL |
| Nm | 1: | rpm | ||||
| HFT003L | 3000 | 5-21 | 4000 | √ | √ | OMNI SL02 Auburn Gear Model 40 |
| HFT005L | 5000 | 5-75 | 4000 | √ | √ | OMNI SD06/SL06 Auburn Gear Model 6B Auburn Gear Model 7 |
| HFT010L | 10000 | 35-79 | 4000 | √ | √ | OMNI SL12 Auburn Gear Model 8b |
| HFT017L | 17000 | 18-171 | 4000 | √ | Rexroth GFB17 Auburn Gear Model 9 | |
| HFT024L | 24000 | 38-222 | 4000 | √ | Rexroth GFB24 Auburn Gear Model 10B | |
| HFT026L | 26000 | 18-63 | 4000 | √ | Rexroth GFB26 | |
| HFT036L | 36000 | 24-270 | 4000 | √ | Rexroth GFB36 | |
| HFT040L | 40000 | 20-66 | 4000 | √ | Rexroth GFB40 | |
| HFT045L | 46000 | 66-205 | 4000 | √ | Siebenhaar | |
| HFT050L | 50000 | 28-1817 | 4000 | √ | Rexroth GFB50 | |
| HFT060L | 60000 | 26-510 | 3500 | √ | Rexroth GFB60 | |
| HFT080L | 80000 | 40-190 | 3500 | √ | Rexroth GFB80 | |
| HFT110L | 11000 | 29-219 | 3500 | √ | Rexroth GFB110 |
Key features Two- or three-stage planetary drive with reduction ratios of up to 1:153
Optimized gear design for maximum efficiency and minimum noise
Integrated, low voltage, 3 phase induction motor with inverter
Integrated, high accuracy, KTY temperature sensor
High resolution, Hall effect speed sensor
Elite HFTE planetary drives incorporate an integrated, maintenance-free electric motor and offer significant benefits, including compact dimensions, low noise and high efficiency. HFTE Series drives are designed for use with all kinds of aerial platforms and other types of mobile machinery, for indoor and outdoor use. This advanced powertrain solution uses a two- or three-stage gearbox offering reduction ratios of up to 1:153 to satisfy the widest possible range of needs. The gearbox is coupled with a low-voltage induction motor (BT Series), specially developed for traction power and control applications.
