Product Description:
This LiFePO4 Battery Pack is an innovative solution designed for high-performance energy storage needs. It supports both series and parallel connection to 24V and 48V systems, making it ideal for residential, industrial, and commercial applications. The hardware BMS and robust plastic case ensure the highest level of safety and performance. With a compact and lightweight design, it offers an excellent replacement for traditional lead-acid batteries, providing significant savings in weight and increased cycle life. This battery is also equipped with optional Bluetooth monitoring, enabling easy control and diagnostics.
| MODEL SPECIFICATION | Li-MAX 12.8V50AH | Li-MAX 12.8V100AH | Li-MAX 12.8V150AH | Li-MAX 12.8V200AH | Li-MAX 25.6V100AH | Li-MAX 25.6V150AH |
| Battery Type | LiFeP04 | LiFePO4 | LiFeP04 | LiFePO4 | LiFePO4 | LiFeP04 |
| Normal Battery Model | 12.8V50AH | 12.8V100AH | 12.8V150AH | 12.8V200AH | 25.6V100AH | 25.6V150AH |
| Normal Capacity(25℃,0.2C) | 640WH | 1280WH | 1920WH | 2560WH | 2560WH | 3840WH |
| Voltagewindow(Vdc) | 11.2～14.6V | 11.2～14.6V | 11.2～14.6V | 11.2～14.6V | 22.4～29.2V | 22.4～29.2V |
| Folat Charge Voltage(Vdc | 14.0V | 14.0V | 14.0V | 14.0V | 28.0V | 28.0V |
| Max.continue discharge current | 50A | 100A | 100A | 200A | 100A | 150A |
| Max.pulsedischarge current | 100A 1Sec | 200A1Sec | 200A1Sec. | 300A1Sec | 200A1Sec | 200A1Sec |
| Max.continue charge current | 25A | 50A | 100A | 100A | 50A | 75A |
| Cells Brand | Guoxuan | CATL | CATL | CATL | CATL | CATL |
| Cycle life(+25℃0.2C 100%DoD) | >5000 Cycles | |||||
| Terminal | M6 | M8 | ||||
| Storagetemperature | 0℃~30℃ | |||||
| Storage duration | 6 months at25℃ | |||||
| Safety standard | UN38.3,MSDS,CE | |||||
| IP degree | IP65 | |||||
| PROTECTION | ||||||
| Protection | Overcharge protection,Over discharge protection,Over current protection, Shortcircuit protection,Overtemperature protection | |||||
| AMBIENT | ||||||
| Working Temperature | -10℃~+50℃ | |||||
| Humidity | 0~95%(no condensation) | |||||
| Sea Level(m) | ≤1500 | |||||
| DIMENSION | ||||||
| L×W×H(products size)mm | 231*145*211 | 332*172*220 | 484*170*240 | 522*218*238 | 522*218*238 | 522*218*238 |
| L×WXH(package size)mm | 239*154*252 | 342*181*265 | 497*180*292 | 532*252*268 | 532*252*268 | 532*252*268 |
| Weight(NWKg) | 5.5kg | 12.0kg | 15.0kgs | 27.0Kg | 27.0Kg | 30.0Kg |
| Weight(GW Kg) | 6.0kg | 13.0kg | 16.0kg | 28.0Kg | 28.0Kg | 32.0Kg |
Application:
Perfect for use in solar energy storage systems, backup power for telecom base stations, and any application where reliable, long-lasting, and efficient energy storage is required. The LiFePO4 Battery Pack is designed for both indoor and outdoor installations, with a high IP65 protection rating, ensuring optimal performance under harsh environmental conditions.
Shipping Methods
Supports global air and sea shipping.
