460 HP Tow Truck G7 VI Sitrak Shipping Cost and 6 Months After-sales Service Included
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product use
1. Definition of tractorA tractor is a versatile light truck that excels in towing other vehicles or objects, typically equipped with one or more pairs of wheels and axles. Known for its reliability, it effortlessly pulls heavy-duty vehicles like semi-trailers, luxury yachts, and construction equipment, making it indispensable in the realm of heavy transport.
2. the structure of the tractor
A tractor is meticulously engineered with essential components such as the engine, transmission, tires, and frame. Enhanced functionality is achieved with optional features like tow hooks, advanced locking systems, and remote controls, ensuring superior operation and precise control.
3. tractor application field
1. Transportation: Tractors are vital in the long-distance freight industry, adept at towing semi-trailers and large trucks, ensuring the safe and efficient delivery of goods to their destinations.
2. Construction field: Tractors are crucial for towing various construction machinery, including excavators, bulldozers, and cranes, facilitating the transport of heavy equipment to construction sites efficiently.
Basic Info.
Parameter configuration
Basic Information
| Announcement Model: | ZZ5316CCYV466HF1B | type: | Saddle Truck |
| Drive type: | 8X4 | Wheelbase: | 1950+4600+1400mm |
| Box length level: | 9.5 m | engine: | Sinotruk MC11.46-61 |
| Gearbox: | Sinotruk HW25712XSTCL | Rear axle ratio: | 3.7 |
| Body length: | 11.99 m | Body width: | 2.55 m |
| Ride height: | 3.98 m | Front track: | 2022/2022mm |
| Rear track: | 1830/1830mm | Vehicle weight: | 15.5 tons |
| Rated load: | 15.37 tons | Total mass: | 31 tons |
| Maximum speed: | 89KM/h | Origin: | Zhangqiu, Shandong |
| Tonnage level: | Heavy trucks | driver license: | A1,A2,B2 |
| Approach Angle: | 19 degrees | Departure angle: | 18 degrees |
| Front overhang/rear overhang: | 1.492/2.548m | Fuel Type: | diesel fuel |
Engine parameters
| engine model: | Sinotruk MC11.46-61 | Engine Brand: | Sinotruk |
| Engine common name: | Sinotruk MC11 | Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel | Cylinder arrangement: | series |
| Displacement: | 10.518L | Emission Standards: | National VI |
| Maximum output power: | 338kw | Maximum horsepower: | 460 hp |
| Maximum Torque: | 2200N·m | Maximum torque speed: | 1000-1400RPM |
| Rated speed: | 1900RPM | Engine Type: | Inline six-cylinder, water-cooled, four-stroke, supercharged, intercooled, high-pressure common rail |
Cargo box parameters
| Cargo box form: | Barn type | Length of cargo box: | 9.52 m |
| Cargo box width: | 2.45 m | | |
Cab parameters
| Cab width: | 2440mm | Number of passengers allowed: | 3 people |
| Number of Seat Rows: | Half row | | |
Gearbox parameters
| Gearbox Model: | Sinotruk HW25712XSTCL | Gearbox brand: | Sinotruk |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Number of downs: | 2 | | |
tank
| Fuel tank capacity: | 1000L | | |
Chassis parameters
| Permissible load on front axle: | 6500/7000KG | Permissible load on rear axle: | 17500(two-axis group)KG |
| Speed ratio: | 3.7 | Number of springs: | 3/3/4 |
tire
| Tire specifications: | 12R22.5 18PR | Number of tires: | 12 |
Control configuration
| ABS anti-lock braking system: | | | |
Shipment
We usually ship the truck by RO-RO vessel or bulk vessel. We also can ship the truck by the special container.
Original Spare Parts
We provide authentic Spare Parts and boast a comprehensive after-sales service system. Our After-market Division is dedicated to delivering exceptional service with a streamlined supply chain that ensures rapid parts delivery.
Our Product
Thanks to Choose us
Q: How about the delivery time?
A: Most of our trucks and machinery are in stock, enabling delivery within 7 days. For specially ordered items, typical production time is around 30 days.
Q: How many units of truck does you have per year?
A: We produce nearly 30,000 units annually, with approximately 5,000 units updated each month.
Q: How do you control the quality of product?
A: Our factory features a standardized production workshop with highly trained workers. Each product undergoes a meticulous inspection process. We ensure our trucks and machinery are reconditioned to professional standards.
Q: Do you accept custom order? What's is your MOQ order?
A: Yes, we accept custom orders with a minimum order quantity (MOQ) of just 1 unit.
