Carbon Steel Hydraulic Cement Mixer Truck 8x4 for Durable and Performance by Sinotruk
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
Introducing the Sinotruk Hydraulic Steering Concrete Mixer Truck-a specialized marvel crafted for the seamless transportation of concrete to construction sites. Fondly known as the 'field snail car' or 'olive car' due to its distinctive shape, these vehicles feature cylindrical mixers that guarantee the secure and efficient delivery of mixed concrete. Experience the pinnacle of reliability and performance with each journey.From start to finish, the mixing drum never ceases to rotate, preventing the concrete from setting. Upon reaching the destination, the drum is meticulously washed out with water to remove any residual concrete. This essential process averts hardening, ensuring the mixer remains ready for optimal performance in future tasks.
Basic Info.
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Explore Detailed Images for SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo shacman | |
| Cabin | Driving type 8x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro II | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
Our extensive range of used tipper trucks,tractor trucks, and concrete mixer trucks, dating from 2013 onwards, are in impeccable condition and offered at highly competitive prices!For additional images and further details, please feel free to contact us.
Precautionary Measures
1. Perform a comprehensive inspection of all mechanical components before startup to ensure all systems are in perfect working order.
2. Ensure the mixing lever is in the neutral position before starting the engine.
3. After engine startup, set the lever to the discharge position and drain any residual water from the cylinder.
4. During loading, carefully place the stirring rod into the specified loading slot.
5. Secure the discharge chute in the traveling position to prevent any unintended movement during transportation.
6. When operating the joystick, always pause momentarily in the neutral position before moving to the next position.
7. Maintain a pristine work environment. Avoid careless disposal of excess materials. After discharging, thoroughly clean the mixing drum, tank, rollers, and other components. When removing hardened concrete from inside the cylinder, ensure the vehicle is powered off, the key is removed, and an external observer is monitoring the procedure.
