Manual Transmission Type Sinotruk Cement Mixer Truck for Heavy Duty Construction Needs
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
The Sinotruk Hydraulic Concrete Mixer Truck is a cutting-edge marvel engineered for seamless concrete transportation to construction sites. Boasting an unparalleled design, likened to a field snail or olive car, it ensures unmatched efficiency in delivering mixed concrete. Its cylindrical mixers are meticulously crafted for peak performance, rendering this truck an invaluable asset for any construction endeavor.The mixing drum of the Sinotruk Hydraulic Concrete Mixer Truck remains in continuous rotation during transit, ensuring the concrete's fluid state. Upon arrival, the drum undergoes a thorough rinsing with water to prevent any residual concrete from hardening, thus preserving its full operational capacity and extending its longevity.
Basic Info.
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Detailed Pictures for SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro II | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We offer a diverse range of used tipper trucks,tractors, and concrete mixer trucks, all from 2013 onwards. Each vehicle is in pristine condition and available at incredibly competitive prices!For more detailed photos and comprehensive information, please contact us.
Matters Needing Attention
1. Conduct a meticulous inspection of all mechanical components before starting the vehicle. Proceed only if the system is verified to be in excellent condition.
2. Ensure the mixing lever is in the 'neutral' position before starting the engine.
3. Once the engine is running, switch the mixing lever to the 'discharge' position to expel any residual water from the cylinder.
4. During loading, set the stirring operating rod to the 'loading' position.
5. Secure the discharge groove in the 'traveling' position before transportation to prevent any swinging.
6. When maneuvering the joystick, always allow a brief pause in the 'neutral' position before moving to the next setting.
7. Uphold high standards of civilized construction practices: avoid indiscriminate disposal of excess materials. After discharging, thoroughly clean the mixing drum, tank, roller, and other components. When entering the cylinder to remove concrete residues, ensure the vehicle is off, the key is removed, and supervision is provided from outside.
Our Factory
Shipment
We primarily ship our trucks via RO-RO vessel or bulk vessel. Special container shipping arrangements can also be made upon request.
Original Spare Parts
We provide authentic spare parts. Our diligent after-sales service team, managed by the After-market Division, ensures unmatched support and an efficient supply chain for swift parts delivery.
Our Product
Thank You for Choosing Us
Q: How about the delivery time?
A: We typically have most of our trucks and machines in stock, enabling delivery within 7 days. Custom orders usually require a production time of approximately 30 days.
Q: How many units of trucks do you produce annually?
A: We manufacture around 30,000 units annually, with nearly 5,000 units updated monthly.
Q: How do you control product quality?
A: Our factory is equipped with a state-of-the-art production workshop staffed by highly trained professionals. Each product undergoes rigorous inspections. We also recondition trucks and machines through a professional and meticulous process.
Q: Do you accept custom orders? What is your MOQ?
A: Yes, we do accept custom orders. Our minimum order quantity (MOQ) is just 1 unit.
