Manual Transmission Type Sinotruk Chassis HOWO 12m3 Concrete Mixer Truck for Heavy-Duty
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
The Sinotruk Chassis HOWO 12m3 Standard Concrete Mixer Truck is a precision-engineered vehicle crafted for the seamless transportation of concrete to various construction sites. Its distinctive design, often likened to a field snail car or olive car, is equipped with cutting-edge cylindrical mixers. These mixers guarantee the safe and efficient conveyance of pre-mixed concrete, ensuring your projects run smoothly.
The innovative mixing drum of our truck continuously rotates during transit to prevent the concrete from hardening. Post-delivery, the drum is meticulously washed with water to eliminate any residual concrete, maintaining the drum's optimal capacity and performance for future tasks.
Basic Info.
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Detailed Pictures for SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro 3 | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We provide a premium selection of used tipper trucks,tractor trucks, and concrete mixer trucks from the year 2013 onwards. Each vehicle is in excellent condition and offered at highly competitive prices!For more photos and in-depth details, please contact us.
Matters Needing Attention1. Perform a thorough inspection of all parts of the mechanical system before starting to ensure flawless operation.
2. Before starting, make certain that the mixing lever is set to the "neutral" position.
3. After starting, switch the mixing lever to the "discharge" position to eliminate any water from the cylinder.
4. When loading, adjust the stirring operating rod to the "loading" position.
5. Secure the discharge groove in the "traveling" position before transportation to prevent it from swinging.
6. During joystick operation, briefly pause in the "neutral" position before moving to the next position.
7. Maintain a spotless work area; avoid pouring excess materials randomly. After discharging, clean the mixing drum, tank, roller, and related components. If entering the cylinder to remove concrete clumps, ensure the vehicle is off, the switch key is removed, and have someone monitor from outside.
Our Factory
Shipment
We typically ship our trucks via RO-RO vessel or bulk vessel. Special containers can also be arranged if necessary.
Original Spare Parts
We offer genuine spare parts and an extensive after-sales service system that ensures outstanding support. Our efficient supply chain guarantees prompt and reliable delivery.
