Sinotruk HOWO Concrete Mixer Truck and Air Conditioner Cab for Maximum Efficiency
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
The Mixer Truck is a specialized vehicle meticulously engineered to transport concrete for construction projects. Often called a field snail car or olive car due to its distinctive design, it features cylindrical mixers that guarantee the secure and efficient delivery of pre-mixed concrete.
The mixing drum rotates continuously during transit, preventing the concrete from setting. After delivery, the drum is thoroughly washed with water to remove any residual concrete, maintaining optimal capacity for subsequent use.
Basic Info.
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Detailed Pictures for SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro 3 | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We provide a diverse range of used tipper trucks,tractor trucks, and concrete mixer trucks from 2013 onwards, all in pristine condition and offered at competitive prices!For more photos and details, please contact us.
Matters Needing Attention1. Conduct a thorough inspection of all mechanical system parts before starting to ensure optimal working condition.
2. Before starting, make sure the mixing lever is in the "neutral" position.
3. After starting, shift the mixing lever to the "discharge" position to expel any water from the cylinder.
4. While loading, position the stirring operating rod to the "loading" position.
5. Secure the discharge groove in the "traveling" position prior to transportation to prevent it from swinging.
6. When maneuvering the joystick, briefly pause in the "neutral" position before moving to the next position.
7. Maintain a clean workspace; avoid pouring excess materials randomly. After discharging, clean the mixing drum, tank, roller, and related parts. If entering the cylinder to remove concrete clumps, ensure the vehicle is off, the switch key is removed, and someone monitors from outside.
Our Factory
Shipment
We typically ship trucks via RO-RO vessels or bulk vessels, with the option to use special containers if necessary.
Original Spare Parts
We supply genuine spare parts and offer an extensive after-sales service system to ensure unparalleled support, utilizing an efficient supply chain for prompt delivery.
