12m3 Sinotruk Chassis Hydraulic Steering Concrete Mixer Truck for Quick Construction
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
The Mixer Truck is a specialized vehicle meticulously engineered for the transportation of concrete, vital for construction endeavors. With its distinctive design, it has earned nicknames like 'field snail car' or 'olive car.' Outfitted with advanced cylindrical mixers, these trucks are pivotal in guaranteeing the safe and efficient conveyance of pre-mixed concrete to your site.
The mixing drum perpetually rotates during transit to thwart the concrete from setting. After delivery, it undergoes a thorough water wash to eliminate any residual concrete, thus preserving the drum's capacity for successive uses.
Basic Info.
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Explore Detailed Pictures of SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro 3 | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We offer a diverse selection of used tipper trucks,tractor trucks, and concrete mixer trucks from 2013 onwards, all boasting excellent condition and competitive pricing!For additional photos and details, please contact us.
Matters Needing Attention1. Conduct a meticulous inspection of all mechanical system components before starting to ensure optimal working condition.
2. Prior to ignition, confirm the mixing lever is set to the 'neutral' position.
3. Once started, shift the mixing lever to the 'discharge' position to expel any water from the cylinder.
4. During loading, adjust the stirring operating rod to the 'loading' position.
5. Secure the discharge groove in the 'traveling' position before transit to prevent unwanted swinging.
6. When maneuvering the joystick, ensure it briefly pauses in the 'neutral' position before transitioning to the next.
7. Maintain an immaculate work area; refrain from indiscriminate material disposal. After discharge, rigorously clean the mixing drum, tank, roller, and associated parts. While entering the cylinder to remove concrete lumps, ensure the vehicle is powered down, the key is removed, and supervision is present.
Our Factory
Shipment
We typically ship our trucks by RO-RO vessel or bulk vessel, with special containers available upon request.
Original Spare Parts
We supply genuine spare parts. Our robust after-sales service system ensures unparalleled support, leveraging an efficient supply chain for prompt and reliable delivery.
