CE Certification 12m3 Concrete Mixer Truck with Sinotruk Chassis and Performance
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
Our Mixer Truck is a highly specialized vehicle, expertly crafted to facilitate the transportation of concrete, indispensable for any construction project. With its unique and recognizable design, it has garnered nicknames such as 'field snail car' or 'olive car.' Equipped with state-of-the-art cylindrical mixers, these trucks play a crucial role in ensuring the safe and efficient delivery of pre-mixed concrete to your construction site.
The mixing drum continuously rotates during transit to prevent the concrete from hardening. Once delivery is complete, the drum undergoes a comprehensive water wash to remove any remaining concrete, thus maintaining its capacity for future uses.
Basic Information
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Description
Discover In-Depth Images of SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro 3 | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We provide a wide array of used tipper trucks,tractor trucks, and concrete mixer trucks from the year 2013 onwards. Each vehicle is in excellent condition and offers competitive pricing!For more photos and detailed information, please reach out to us.
Important Considerations1. Conduct a thorough inspection of all mechanical system components before starting to ensure they are in optimal working condition.
2. Before ignition, make sure the mixing lever is set to the 'neutral' position.
3. After starting the engine, move the mixing lever to the 'discharge' position to remove any water from the cylinder.
4. During loading, shift the stirring operating rod to the 'loading' position.
5. Secure the discharge groove in the 'traveling' position before transit to prevent any unwanted movement.
6. When maneuvering the joystick, ensure it momentarily pauses in the 'neutral' position before moving to the next.
7. Maintain a clean work environment. Avoid indiscriminate disposal of materials. After discharge, thoroughly clean the mixing drum, tank, roller, and associated parts. If entering the cylinder to remove concrete lumps, ensure the vehicle is powered down, the key is removed, and supervision is present.
Our Factory
Shipment Details
We typically ship our trucks using RO-RO vessels or bulk vessels. Special containers are available upon request.
Genuine Spare Parts
We provide authentic spare parts. Our extensive after-sales service system guarantees unmatched support, utilizing an efficient supply chain for prompt and dependable delivery.
