Euro 3 Standard 12m3 Concrete Mixer Truck with Hydraulic Steering and Sinotruk Chassis
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Purpose of the Product
The Mixer Truck is a sophisticated piece of machinery specifically designed for the transportation of concrete, a crucial element in construction projects. With its unique configuration, it has garnered nicknames such as 'field snail car' or 'olive car.' Equipped with state-of-the-art cylindrical mixers, these trucks are instrumental in ensuring the safe and efficient delivery of pre-mixed concrete directly to your construction site.
The mixing drum continuously rotates during transit to prevent the concrete from hardening. Upon delivery, it undergoes a comprehensive water cleaning to remove any leftover concrete, thus maintaining the drum's usability for future operations.
Essential Information
| Model NO | ZZ1257N3647N1 | Productivity | 180m²/h | |
| Feeding Height | 1380mm | Vibrating Amplitude | 0.9mm | |
| Certification | ISO9001: 2000 | Condition | Used | |
| Color | White | Cbm | 10/12cbm | |
| Customlize | Support Customlize | Water Tank | 450L | |
| Overall Dimension | 9000*2550*3950 mm | Transmission | Hw19710, 10f & 2r with Pto | |
| Transport Package | Nude | Specification | 8800x2550x3800mm | |
| Trademark | HOWO | Origin | Shandong | |
| Production Capacity | 200/months |
Product Overview
Discover High-Resolution Images of the SINOTRUK 10CBM 12CBM HOWO 10 Wheeler Concrete Mixer Truck
| brand | Sinotruk Howo | |
| Cabin | Driving type 6x4, LHD | |
| HW76 single bed | ||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 10245x2496x3450 |
| Wheel base (mm) | 3600+1350 | |
| Wheel track (front/rear) (mm) | 2022/2022 | |
| Approach/Departure angle(°) | 16/24 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
| Model | WD615.47 | |
| Horse Power(HP) | 371 | |
| Emission standard | Euro 3 | |
| Gearbox | 10 forwards & 2 reverse | |
| Steering | Left hand drive | |
| Tire | 12R22.5 tubeless tires with one spare | |
| Mixer Drum | Mixer Capacity | 16 cubic meters |
| Drum thickness | 6mm | |
| Blade thickness | 4mm | |
| Tanker Material: | 16MnQ345 Carbon Steel | |
| Filling Rate(%) | 59 | |
| Input Speed (m3/min) | ≥2.8 | |
| Output Speed (m3/min) | ≥1.2 | |
| Surplus Ratio | ≤0.5 | |
| | Tanker Rotate Speed(rpm) | 0~17 |
| | Hydraulic Pump | Italy Brand: PMP |
| Drum Drive System | Hydraulic Motor | Italy Brand: PMP |
| | Speed Reducer | Germany Brand |
| | Radiator | KAITONG |
| | Water Tank Volume(L) | 400 |
We provide a wide range of used tipper trucks,tractor trucks, and concrete mixer trucks from 2013 onwards, all in superb condition and competitively priced!For additional photographs and further details, please reach out to us.
Important Considerations1. Conduct a thorough inspection of all mechanical components before starting to ensure they are in optimal working condition.
2. Before ignition, make sure the mixing lever is set to the 'neutral' position.
3. Once the engine is started, move the mixing lever to the 'discharge' position to expel any water from the cylinder.
4. During loading, adjust the stirring operating rod to the 'loading' position.
5. Secure the discharge groove in the 'traveling' position before transit to prevent unnecessary swinging.
6. When moving the joystick, ensure it briefly pauses in the 'neutral' position before switching to the next.
7. Maintain a clean work area; avoid arbitrary material disposal. After discharge, thoroughly clean the mixing drum, tank, roller, and associated parts. If entering the cylinder to remove concrete lumps, ensure the vehicle is powered down, the key is removed, and supervision is present.
Our Manufacturing Facility
Shipping
We usually ship our trucks by RO-RO vessel or bulk vessel, with special containers available upon request.
Authentic Spare Parts
We supply genuine spare parts. Our comprehensive after-sales service system ensures unparalleled support, utilizing an efficient supply chain for prompt and reliable delivery.
