PC220-10 PC230-10 Hydraulic Crawler Excavator for Original Construction Machinery
Price:
$35,000.00/pieces 1-4 pieces
MOQ:
1 set
Delivery Time:
Negotiable
Brand:
HJH
Product Description
Company Profile
Product Display
Basic parameters
工作重量Working weight | 22300KG |
发动机额定功率power | 124KW/2050rpm |
铲斗容量Bucket Capacity | 1.0-1.2m3 |
液压系统Hydraulic System | 林德Linde |
行走马达Walking motor | 日本纳博NABTESCO |
发动机型号Engine Model | 康明斯Cummins /五十铃Isuzu |
Dimensions
总长（运输时）mm Overall length | 9425 |
总宽度mm Overall width | 2980 |
总高度（动臂顶部）mm Transport height | 2970 |
上部宽度mm Overall width of upperstructure | 2710 |
总高度（驾驶室顶部）mm Overall height of cab | 3040 |
标准履带板宽度mm Shoe width | 600 |
轨距mm Track gauge | 2380 |
最小离地间隙mm Min. ground clearance | 440 |
尾部回转半径mm Tail swing radius | 2710 |
履带接地长度mm Track ground length | 3480 |
履带长度mm Track length | 4260 |
Performance specifications
整机重量（kg）Machine Weight | 22300 |
斗容m³Bucket capacity | 1.0-1.2m³ |
额定功率KW/rpm Rated Power | 124/2050 |
行走速度（高/低km/h）Travel speed(H/L) | 5.5/3.3 |
回转速度rpm Swing speed | 11 |
爬坡能力（35°）Gradeability | 70% |
接地比压kpa Ground pressure | 43.2 |
铲斗挖掘力KN Bucket digging force | 150 |
斗杆挖掘力KN Arm digging force | 109 |
Why Choose Us
Service attitude is good
Product quality is guaranteed
Team has been established for a long time and we have rich work experience
Product quality is guaranteed
Team has been established for a long time and we have rich work experience
Wide global transportation range
Many positive reviews from customers
FAQ
How to solve quality or usage issues that arise after receiving the product?
We will provide online assistance, one-on-one guidance on how to use our products. If there are problems during the warranty period, we will also provide certain compensation or returns.Similar Products
