180-200KW Copper Brushless Generator Diesel Engine Original and Genuine Products
Price:
$2,150.00/pieces 1-4 pieces
MOQ:
1 pcs
Delivery Time:
Negotiable
Brand:
Lingyu
Product Description
Products Description
Voltage :120~690V Power :225~3438KVA Features: Meets generator standard requirements Self-excitation control or optional permanent magnet generator provides continuous short-circuit current capability Class H insulation meets harsh environmental requirements Two-thirds of the winding pitch inhibits excessive midline current The 12 stator outlet ends can be reconnected Single pivot structure Easy to install and maintain Standard IP23 protection class Unidirectional rotating fan Dedicated single fulcrum SAE2/11.5 or SAE1/14 connections Options or attachments: Winding temperature sensor RTD Bearing temperature sensor RTD Winding temperature protection thermistors and relays An optional permanent magnet generator provides excitation to isolate the control system from the output Optional Zone 1 341 or J321.4 billion, the optional three-phase induction detection module enables the 4S4404 you can meet the voltage adjustment rate of 05% anti-condensation heater Air filter Pendent transformer running in parallel Anti-radio interference suppressor Power Factor Controller PFC3 IP44 protection class
Flange type transition bushing | ||||||||||||
SAE NO. | R | S | T | W | X | y | ||||||
1 | 10 | 12.7 | 530.2 | 511.17 | 553 | 575 | ||||||
2 | 10 | 11.0 | 466.7 | 447.6 | 489 | 575 | ||||||
SAE NO. | AN | AR | AS | AT | V | / | ||||||
1 | 39.68 | 11.08 | 380.1 | 333.3 | 352.35 | |||||||
2 | 25.4 | 8 | 13.5 | 438.2 | 466.67 | |||||||
Transportation data | ||||||
Net weight kg | Gross weight kg | BoX size cm | ||||
KHI 180 | 720 | 760 | 117x64x99 | |||
KHI 200 | 740 | 760 | 117x64x99 | |||
All figures, weights and prices are for reference only.
If in doubt, please contact the sales Manager and refer to the outline.
1. About color difference All products are shot in kind, color difference is unavoidable, due to the display, taking photos and drawing process may occur subtle color deviation color, please refer to the actual subject. 2. Price description The price of the page is for reference only, please contact the sales manager to communicate, thank you! All the products in this shop are physical sources, quality is guaranteed, if you have other questions, please consult the sales manager. 3. Goods signing In order to protect the quality of your goods and related rights and interests, please check the goods in the presence of the Courier. If the goods are damaged or inconsistent with the product, please contact us in time, we will check with you the first time, thank you for your cooperation. 4. About delivery The actual delivery time shall be subject to the agreed time between the two parties. In order to allow you to receive the products in good condition, pay attention to check whether the packaging is in good condition and whether the product quantity is correct when signing for the goods. 5, about after-sales All products go through a strict quality inspection process before delivery to confirm product quality. Please check carefully before receiving the goods. If you have any questions, please contact us in time. In case of product quality problems, please provide product pictures, we will deal with the problem as soon as we confirm it, thank you for your support.
Petrochemical industry
Power plant
Construction industry
Automobilemanufacturing
Sand blast and shot blasting
Powder coating
Packaging Details | ||
Carton | For the small quantity engine spareparts, we use the carton in general | |
Plywood Case | For the heavy and big volume productswe use the plywood case in general. | |
Packaging Details | The normal package is carton andplywood case. There are neutral packing all.lf our client have demand, we willpacking or pack it according tocustomers specialrequest. | |
Shipping | ||
smallorder | DHL I TNT / FedEx / EMS / UPS withfaster speed and competitive freight | |
large order | Air / Sea shipment | |
Delivery Details | The freight will be paied by buyer ingeneral, because we often use FOBtrade terms. | |
Professional sales and after-sales service team Shaanxi Kanglongsi Auto Parts Co., LTD., is a professional engaged in diesel engine machine, engine parts sales, and after-sales maintenance three guarantee service brand company. Mainly engaged in Cummins, Volvo, Carter, Perkins, Weichai, Yuchai and other brands of diesel engine units, engine parts, as well as special oil and antifreeze sales and after-sales service. Fast delivery Thank you for your support, we have the largest logistics warehousing center in Northwest China, all spot transactions, to ensure that the contract signed within 1 week to complete the delivery. Official purchasing channel With professional after-sales service experience and official procurement channels, we believe that we can make you satisfied with the best price, the best quality products and the fastest service. After-sales and warranty The company has a perfect sales and after-sales service team of 15 people, set up a 24-hour on-duty service phone, professional answer a series of problems in the use of products!
Q:How long will you reply me? A:We will contact you as soon as possible but within 12 hours Q: Can I get some samples? A: Yes,Sample order is available for quality check and market test. But you have to pay the express cost. Q: How soon can you arrange your production? A: Once getting your product confirmation and receiving the prepayment, the production will be started immediately. Q: What''s delivery time? A: It depends on products, We can ship within 2 days of we have stock and It usually takes about 6-8 working for custom products Q:How do you control your quality ? A: Three inspection steps(of original, production, and finished goods) + good warranty service(1 year free to change a new one without any human damage factors).Explosion-proof certification, RoHs ready. And before the delievry of goods, quality and safety inspection certification issued by third parts also can be offered. Q:Could I visit your factory? A:Very welcome! Fly to Xian Yang air port. It was a big pleasure for us. Q: What''s your warranty terms? A: We offer 12 months warranty time. Q:Can you provide OEM & Customized service? A:Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
