OEM 36V 48V 72V Lithium LiFePO4 Golf Trolly Batteries Pack 100Ah 200Ah
OEM ODM 36V 48V 72V Golf Cart Lithium LiFePO4 Battery Pack 100Ah 200Ah for Electric Golf Cart
Products Description
1. Safety Performance: safest Lithium Iron Phosphate battery, CE IEC UN38.3 MSDS approved, built-in Smart 200A BMS
2. Long Cycle Life: > 6000 times, 6-8 times life cycle compared to lead acid battery
3. Deep cycle, no memory effect, highly efficient
4. Compact size and lightweight: 1/2 size & weight of lead acid battery
5. Good performance at high temperature
6. Low self-discharge rate: < 3% month
Product Paramenters
| Nominal voltage | (36V)38.4V | (48V)51.2V | (48V)51.2V | (72V)76.8V |
| Capacity (Ah) | 105Ah | 105Ah | 160Ah | 105Ah |
| Battery Energy | 4032Wh | 5376Wh | 8192Wh | 8064Wh |
| Self-discharge | 25℃,≤3% per month | 25℃,≤3% per month | 25℃,≤3% per month | 25℃,≤3% per month |
| Cycle life | >6000 cycles | >6000 cycles | >6000 cycles | >6000 cycles |
| Charge Mode | CC/CV | CC/CV | CC/CV | CC/CV |
| Max. Continuous Charge Current | 100A | 100A | 100A | 100A |
| Charge Cut-off Voltage | 43.8V | 58.4V | 58.4V | 87.6V |
| Max. Continuous Discharge Current | 100A | 200A | 200A | 100A |
| Max. Pulse Current | 200A 10S / 400 5S | 400A 35S / 600A 3S | 400A 35S / 600A 3S | 400A 35S / 600A 3S |
| Discharge Cut-off Voltage | 30V | 40V | 40V | 60V |
| Communication mode | CAN/RS485 | RS485/CAN | RS485/CAN | RS485/CAN |
| Storage temperature | 0~45℃ | 0~45℃ | 0~45℃ | 0~45℃ |
| Working Environment | 0℃ ~ +55℃(Charge) | 0℃~+55℃(Charge) | 0℃~+55℃(Charge) | 0℃~+55℃(Charge) |
| -20℃~+65℃(Discharge) | -20℃~+65℃(Discharge) | -20℃~+65℃(Discharge) | -20℃~+65℃(Discharge) | |
| Water Dust Resistance | IP67 | IP67 | IP67 | IP67 |
| Housing Material | Metal case | Metal case | Metal case | Metal case |
| Bluetooth 5.0 | Yes | Yes | Yes | yes |
| GPS Feature | Optional | Optional | Optional | optional |
| Display Screen | Optional | Optional | Optional | optional |
| OEM & ODM | Optional | Optional | Optional | optional |
| Dimension | 425*318*252mm | 500*318*230mm | 573*369*270mm | 800*310*270mm |
| Weight | 83.78lbs.(38Kg) | 99.21lbs.(45kg) | 149.91lbs.(68kg) | 198.00lbs.(78kg) |
| Compatible | Electric Golf Carts,YAMAHA,Club Car,EZGO,ICON,Golf Trolley,Electric Utility Vehicle,Sightseeing Car,Hunting Car,Electric Truck, Electric Tractors | |||
FAQ
Q: Can your company accept OEM and ODM order?
A: Yes, we can, we are a plant with more than 10 years OEM and ODM experience, many of our customers have made big success in their field.
Q: Will this battery work well on my power tool just as my original battery?
A: 100% Compatible with your power tool battery, it works well as your original power tool battery
Q: What are the main cells of your products?
A: We have imported batteries and domestic batteries, imported batteries mainly use imported batteries from Sony, Samsung and LG brands as our power tool batteries, with 100% high quality.
Q: Does your product have an after-sale guarantee? How long is the warranty?
A: All our products have passed relevant quality inspection and certification, can be exchanged within 15 days, and guaranteed for 12 months.
Q: What certifications have the products of your factory passed?
A: All our products have FCC, CE, ROHS certification, quality inspection report and MSDS, shipping inspection report.
