48V 300Ah Battery Lithium Ion Ups Rackmount 10kwh Solar Energy Storage
51.2V 48V 100ah 200Ah 300Ah LiFePO4 Lithium Ion Iron Phosphate Battery Rack Mounted 10kwh Solar Energy Storage Battery
Weight 55kg
The charging ratio 0.5C
The discharge rate 1C
Application Power Tools, Home Appliances, Consumer Electronics, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Electric Forklifts
Standard Voltage 51.2VDc
Product name Lithium Iron Phosphate Lifepo4 Battery
Protection Over temperature, over current, short circuit,
Cell Self-Discharge <5 %/ Month
Commumication Protocol CAN/RS485/RS232(WIFI,bluetooth is optional and need extra cost)
Useful Life 8-10 Years
Cycle Life 6000 (@ 80% DoD)
Cell Type Chemistry LiFePO4
Certifications CE,FCC, CCC,IEC
Shipping Classification UN 38.3. UN 3480,MSDS
Product Parameter
Rack-mounted energy storage (Home/Industrial)
| Model | 4850/5150 | 48100/51100 | 48150/51150 | F482001200 |
| Standard Voltage | 48VDc/51.2VDc5 | |||
| Voltage | 39.75-54.75VDc/42.4-58.4VDc | |||
| Norminal Capacity | 50Ah | 100Ah | 150Ah | 200Ah |
| Rated Energy Capacity | 2.4/2.56kWh | 4.8/5.12kWh | 7.2/7.68kWh | 9.6/10.24kWh |
| Commumication Protocol | CAN/RS485/RS232/WIFI/4G/Blue Tooth | |||
| Efficiency (at 0.5C) | 98% | |||
| Cell Self-Discharge | <5 %/ Month | |||
| Maximum Allowed Modules in Parallel | 15 (36/38.4kWh) | 15 (72/76.8kWh) | 15 (108/115.2kWh) | 15 (144/153.6kWh) |
| Depth of Discharge | Up to 100% | |||
| Useful Life | 8-10 Years | |||
| Cycle Life | 6000 (@ 80% DoD) | |||
| Protection | Over temperature, over current, short circuit, over-charging, over-discharging, Low voltage | |||
| Charge Specifications | ||||
| Recommended Charge Current | 25A | 50A | 75A | 100A |
| Maximum Charge Current | 50A | 100A | 100A | 100A |
| Recommended Charge Voltage | 54/57.6V | 54/57.6V | 54/57.6V | 54/57.6V |
| Maximum Charge Voltage | 54.75/58.4V | 54.75/58.4V | 54.75/58.4V | 54.75/58.4V |
| Discharge Specifications | ||||
| Recommended Discharge Current | 25A | 50A | 75A | 100A |
| Maximum Discharge Current | 50A | 100A | 100A | 100A |
| Recommended Low Voltage Disconnect | 41.25/44V | |||
| Battery Low Voltage Protection | 39.75/42.4V | |||
| Battery Recovery Voltage | 45/48V | |||
| Mechanical Specifications | ||||
| Dimenstions | 484*410*120mm | 484*410*178mm | 484*590*178mm | 484*590*178mm |
| Weight | 24.5/26.5kg | 38.5/41kg | 59/63kg | 70.5/75kg |
| Terminal Type | M6 | |||
| Case Material | Industrial Grade Iron | |||
| Enclosure Protection | IP20 | |||
| Installation | Cabinet | |||
| Cell Type Chemistry | LiFePO4 | |||
| Compliance Specifications | ||||
| Certifications | CE,FCC, CCC | |||
| Shipping Classification | UN 38.3. UN 3480, Class 9 | |||
| Temperature Specifications | ||||
| Discharge Temperature | -20~65℃ | -20~65℃ | -20~65℃ | -20~65℃ |
| Charge Temperature | 0~55℃ | 0~55℃ | 0~55℃ | 0~55℃ |
| Storage Temperature | -20~45℃ | -20~45℃ | -20~45℃ | -20~45℃ |
