ASME ASTM Inconel 600 Material Wire Nickel Alloy For Chemical Industry
High-Temperature And Corrosion Resistant Inconel Alloy 600 Wire For Aerospace Industry
Product Introduction
Inconel 600 wire is a high performance nickel based alloy with excellent corrosion resistance and high temperature strength. Its main components include nickel (72%), chromium (14-17%) and iron (6-10%), which gives the alloy excellent corrosion resistance and high temperature stability. Inconel 600 wire can maintain stable mechanical properties in high temperature, oxidative and corrosive environments, and is suitable for a variety of industrial applications. As a high-performance nickel based alloy, Inconel 600 wire plays an irreplaceable role in the chemical industry due to its excellent corrosion resistance, high temperature strength, good processability and low permeability. Its stability and reliability in high temperature and corrosive environment make it perform well in manufacturing various key equipment and components, ensuring the long-term service life and safety of the equipment.
Parameter
Chemical Properties of Inconel 600
| C | Cr | Ni+Co | Al | Ti | Fe | Nb+Ta | Mn | Si | P | S | Cu |
| ≤0.15 | 14.0～17.0 | ≥72 | ≤0.35 | ≤0.50 | 6.0～10.0 | ≤1.0 | ≤1.0 | ≤0.5 | ≤0.04 | ≤0.015 | ≤0.5 |
| ITEM | θ/℃ | TENSIE STRENGTH | HBS | |||
| σb/MPa | σP0.2/MPa | δ5/% | φ/% | |||
| BAR/ROD | 20 | ≥585 | ≥240 | ≥30 | - | 134～217 |
| RING | 20 | ≥520 | ≥205 | ≥35 | - | ≥187 |
| HOT ROLL PLATE | 20 | ≥550 | ≥240 | ≥35 | ≥40 | - |
| 900 | ≥95 | ≥45 | ≥40 | ≥50 | - | |
| COLD ROLLED SHEET | 20 | ≥550 | ≥240 | ≥30 | - | - |
| 900 | ≥90 | ≥40 | ≥60 | - | - | |
| COLD ROLLED SHEET | 20 | ≥550 | ≥200 | ≥30 | - | - |
| STRIP | 20 | ≥550 | ≥240 | ≥30 | - | - |
| WIRE | 20 | - | HV≤151 | |||
|
Shape
|
Size(mm)
|
|
WIre
|
0.5-7.5
|
|
Rod/Bar
|
8.0-200
|
|
Strip
|
(0.5-2.5)*(5-180)
|
|
Tube
|
custom made
|
|
Plate
|
custom made
|
Specific Applications
In the chemical industry, Inconel 600 wire is widely used in the following equipment and components:
- Reactors and storage tanks: used to manufacture chemical reactors and storage tanks. These equipment need to work in high temperature and corrosive environment. The corrosion resistance and high temperature stability of Inconel 600 make it an ideal choice.
- Heat exchanger: used to manufacture heat exchanger to ensure long-term stable operation in high temperature and corrosive environment.
- Pipeline system: used for manufacturing chemical pipeline system, which can resist the erosion of a variety of chemical media, such as sulfuric acid, hydrochloric acid and phosphoric acid.
- High temperature and high pressure equipment: used for manufacturing high temperature and high pressure equipment, such as retort furnace, muffle furnace, heat treatment fixture and basket, vacuum furnace device, etc.
Advantages and Characteristics
- Excellent corrosion resistance:Inconel 600 performs well in a variety of corrosive environments, especially in oxidation and reduction environments at high temperatures. It can resist chloride stress corrosion cracking and is suitable for applications such as chemical processing and seawater desalination. It is very effective for the treatment of hydrogen chloride and chlorine at high temperature. Hydrogen chloride can reach about 538 ° C, and chlorine can be safely used until 510 ° C.
- Excellent high temperature strength:Inconel 600 still has good strength and rigidity in high temperature environment, and can maintain stable mechanical properties at temperatures up to 1100 ° C. After annealing, the tensile strength can reach 550 MPa, the yield strength can reach 210 MPa, and the elongation can reach 30%.
- Good oxidation resistance:Inconel 600 has good oxidation resistance in high temperature oxidation environment, and can form dense oxide film at high temperature to effectively prevent corrosion.
- Excellent processability:Inconel 600 has good cold forming characteristics and can be processed by common processing technologies, such as forging, rolling, bending, etc. The alloy can be processed by heat treatment and welding to ensure the feasibility of manufacturing complex parts.
Contact Us
Email:fbwlau@cnrunlai.com
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
Related Questions and Answers
What are the advantages of Inconel 600 over other alloys?
Inconel 600 has excellent corrosion resistance and oxidation resistance in high temperature and corrosive environment due to its high nickel content, especially in chloride environment. Compared with traditional stainless steel, Inconel 600 has higher strength and stability at high temperature.
What are the custom packaging options for Inconel 600?
Standard export marine packaging: waterproof paper winding+PVC film+bandage+wooden pallet or wooden case.
Customize the packaging according to customer requirements (accept the logo or other content printed on the packaging).
Other special packaging will be designed according to customer requirements.
What is the delivery date of Inconel 600?
Different products have different delivery dates, but they will be delivered as soon as possible on the premise of ensuring quality.
