Brand: KAD
Domestic famous control handle,functional buttons, can control UP/DOWN, FORWARD/BACKWARD sensitively.
Rated load capacity of 1500kg-2000Kg 3m high lifting height multi-directional narrow aisle travelling reach trucks
Price:
CN¥86,482.06/units 1-4 units
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
KAD
Product Description
Product Description
Product Application
The reach stacker truck is suitable for large tonnage and high lift cargo storage applications. The rated load is 1500Kg-2000kg, and the maximum lifting height is 6m. It has the feature of moving the gantry forward as a whole, and the turning radius is small, so that the obstacles at the bottom of the shelves can be ignored. Suitable for large-scale three-dimensional factories, warehouses, supermarkets and wharves to store goods.
Main Features
1. Equipped with electronic drive wheels, making the operation more flexible and convenient, with the function of turning and deceleration. 2. 280Ah large-capacity battery can be used for long time work. 3. One-piece forged forks with stronger load bearing, and the forks come with up and down swinging function. 4. Suitable for all kinds of single-sided, double-sided, tic-tac-toe and chuan-tac-toe pallets. 5. Large oil cylinder ensures the whole gantry to move forward gently and rise and fall smoothly. 6. This forklift has the function of transverse travelling, front and rear sideways travelling.
7. It can turn in place, turn round in place.
Specification
Raise 3m | Raise 3m | Raise 3m | ||
Rated lifting capacity | kg | 1000 | 1500 | 2000 |
Overall curb weight | kg | 1600 | 1800 | 2000 |
Overall length (gantry retracted) | mm | 2467 | 2467 | 2567 |
Overall width | mm | 1317 | 1317 | 1317 |
Static height of gantry | mm | 2080 | 2080 | 2080 |
Maximum fork lift height | mm | 3000 | 3000 | 3000 |
Forward distance | mm | 580 | 580 | 580 |
ground clearance | mm | 65 | 65 | 65 |
Maximum lifting speed (unloaded/full load) | mm/s | 150/90 | 150/90 | 150/90 |
Maximum descent speed (unloaded/full load) | mm/s | 115/380 | 115/380 | 115/380 |
Full load forward speed | mm/s | 195 | 195 | 195 |
Maximum operating speed (unloaded/full load) | km/h | 5.5/4.4 | 5.5/4.4 | 5.5/4.4 |
Minimum outside turning radius | mm | 1600 | 1600 | 1600 |
Maximum climb with full load | % | 5 | 5 | 5 |
Load centre distance | mm | 500 | 500 | 500 |
Travelling motor | kw | 1.5 | 1.5 | 1.5 |
Lifting motor | kw | 3 | 3 | 3 |
Battery rated power | V/Ah | 24/180 | 24/180 | 24/180 |
Drive Wheel Size | mm | 250*80 | 250*80 | 250*80 |
Auxiliary wheel size | mm | 125*50 | 125*50 | 125*50 |
Drive Wheel Type | Pu | Pu | Pu |
Detailed Images
Control Handle
Operation panel
Combined with the key, battery indicator, emergency switch.
Functional panel and beautiful design make work joyful and easy.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas if become our distributor
Our Company
Related Products
Hand Pallet Truck
Manual Stacker
Drum Stacker
Full electric Stacker
Semi-electric Stacker
Electric Reach Stacker
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in paper package and Iron pallet.
We can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. Or As negotiated
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 30 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
