MBR Water Filter Component ABS Plate with Reinforced RPVDF Membrane and High Filtration Efficiency
Price:
CN¥76.09/square meters >=100 square meters
MOQ:
1
Delivery Time:
Negotiable
Product Description
Name | Description |
Material | Hydrophilic PVDF |
Tensile Strength | >300N |
Peel Strength | >0.4MPa |
Size | 2.6/1.8 mm |
Micron rating | 0.1-0.3um |
Porosity | 60-80% |
Flow rating ( pure water) | 1000- 2000L/m2.h.bar |
Operating pressure | 0.01-0.03 MPa |
Temp. | 5-50C |
PH | 2- 12 |
Life time | 5 years |
Products Description
Model | MBR-PVDF-4.5 | MBR-PVDF-10 | MBR-PVDF-16 | ||
Module length | 750MM | 980MM | 1500MM | ||
Module width | 530MM | 650MM | 850MM | ||
Outlet diameter | 25MM | 32MM | 40MM | ||
Module membrane area | 4.5M² | 10M² | 16 M² | ||
Interception pore diameter | 0.1micron | 0.1micron | 0.1micron | ||
Turbidity of water output | ＜1NTU | ＜1NTU | ＜1NTU | ||
Tolerance range of temperature | 5-45℃ | 5-45℃ | 5-45℃ | ||
Tolerance range of PH value | 2-12 | 2-12 | 2-12 | ||
Flow of producing water | 1-1.5 M³/D | 2.4-6 M³/D | 3.5-9 M³/D | ||
Maxtrans membrane pressure(TMP) | -0.05MPA | -0.05MPA | -0.05MPA | ||
Type of water output | Negative pressure suction | ||||
Chemical cleaning agents | Citric acid / sodium hydroxide / sodium hypochlorite | ||||
Q:How is SINOMEMB membrane different from others? A:We offer value against your money, prices which are comparatively lower, performance equivalent to best membranes available and with higher longevity. Q:Are you a manufacturer? A.Yes,we have been in providing the professional products in wire mesh field for more than 10 years. Q:How about the delivery time? A:Usually within7-10days,customized order may need longer time.
