Eco Friendly Hollow Fiber Ultrafiltration Membrane UF 2880 UF Membrane Corrosion Resistance
Price:
Negotiable
MOQ:
1
Delivery Time:
Negotiable
Brand:
SINOMEMB
Product Description
The core SINOMEMB ® series SNU-HO-2-H MAX60 hollow fiber UF membrane element is suitable for high
turbidity raw water systems with a capacity of more than 50 m 3 /hr (220gpm) . Longer module length, larger
effective membrane area, and greater packing density make it one of the modules with the highest effective
membrane area in SINOMEMB ® series UF modules , and its small footprint helps customers To achieve a more
economical membrane system design , its pollution resistance, oxidation resistance and good chemical stability
make it widely used in various water such as surface water, well water, seawater , industrial wastewater, secondary
and tertiary treatment of sewage , etc. Handle the application.
Membrane element operation guide
During the operation of the UF system, it is necessary to avoid sudden changes in pressure during system
start-up, shutdown, operation, cleaning, maintenance, etc., as well as exceeding the maximum withstand pressure
specified in this manual, to prevent possible membrane breakage, sealing, etc. End fall off, membrane shell
cracking and other serious damage consequences; this series of products have been treated with anti-corrosion and
membrane wire protection before leaving the factory, and the inner membrane wire of the module is in a semi-dry
state. For manual operation, the water production rate should be set to 50% of the design water production rate, and
the initial water production must be discharged directly and cannot be used as product water.
Membrane element product usage tips
The normal start-up and normal cleaning and maintenance of the UF system are the key to ensure the long-term
normal use of membrane products. Before starting the system, it should be ensured that the parameters of each
valve, instrument, pre-processing equipment, signal transmission equipment, power equipment, etc. meet the design
specifications and requirements, so as to ensure the safe, stable and up-to-standard operation of the overall system.
Please refer to the product technical manual for the debugging and testing work of the system in the early stage.
Disclaimer
Failure to operate in strict accordance with the operating limits and guidelines set forth herein voids our limited
warranty. If the UF system is out of service, please inject protective liquid inside the membrane module for
anti-corrosion treatment, so as to avoid the increase of maintenance cost caused by the large number of
microorganisms in the system.
