High Efficiency C-Band GaN 50W Power Amplifier Chip YP40601650T for 4400-6000MHz
Price:
36USD each
MOQ:
2 PCS
Delivery Time:
2-7days
Brand:
SZHUASHI
Product Description
SZHUASHI High Efficiency C-Band GaN 50W Power Amplifier Chip YP40601650T for 4400-6000MHz
Product Description
YP40601650T is a 50-watt, internally matched gallium nitride (GaN) high electron mobility transistor (HEMT) designed specifically with high efficiency, high gain and wide bandwidth capabilities, which makes the YP40601650T ideal for multiple applications with frequency from 4400MHz to 6000MHz.
| Pout | 50W |
| Frequency | 4500MHz-6000MHz |
Features
- High Efficiency and Linear Gain Operation
- Negative Gate Voltage and Bias Sequencing Required
- Excellent Thermal Stability and Excellent Ruggedness
- Metal Based Package Sealed with Ceramic-Epoxy Lid
- Gold Metallization System: Chip-Wire Bond-Package
