1800°C U-Shape MoSi2 Heating Element for Dental Furnace with Customizable Sizes and High Oxidation Resistance

Price Negotiable

Price: 200-500 yuan/kg

MOQ: Negotiable

Delivery Time: Negotiable

Brand: KEGU

Product Description

1800°C U-Shape MoSi2 Heating Element for Dental Furnace

MoSi₂ (Molybdenum Disilicide) heating elements are high-performance resistance elements made primarily from pure molybdenum disilicide. When exposed to an oxidizing atmosphere at high temperatures, the surface forms a protective quartz film that prevents further oxidation. These elements are ideal for high-temperature applications ranging from 500°C to 1800°C, including sintering and heat treatment in ceramics, magnets, glass, metallurgy, and refractories.

Product Specifications

Parameter	Specifications
Temperature Grades	1700°C, 1800°C
Available Shapes	U-type, W-type, I-type, L-type, WL-type, Spiral types
Standard Sizes (Diameter/Cold End)	M1700 Series: Φ3/6, Φ4/9, Φ6/12, Φ9/18, Φ12/24 M1800 Series: Φ3/6, Φ4/9, Φ6/12, Φ9/18, Φ12/24

Installation Guide for MoSi2 Heating Elements

Vertical Installation Method

MoSi2 heating elements are brittle at room temperature but become ductile at high operating temperatures. The recommended installation method for U-shaped elements is vertical suspension from the furnace top using specialized support clamps. This approach prevents mechanical stress from concentrating on the heating zone of the element, significantly reducing the risk of fracture and extending service life.

Key Installation Requirements

Support Clamp Selection: Specific support clamps are designed for different element sizes (e.g., 6/12 and 9/18 types)
Precise Alignment: Clamps must be carefully installed to ensure perfect vertical positioning
Proper Insertion: The tapered lower end must fully extend into the furnace chamber to prevent localized overheating
Weight Distribution: Support clamps must bear the entire element weight while maintaining secure positioning

Product Series Classification

Series Type	Operating Temperature	Available Specifications	Configuration Types
1700 Series	Up to 1700°C	Φ6-12 mm	W-type, U-type, L-type, Custom
1800 Series	Up to 1800°C	Φ3-12 mm	U-type, W-type
1800J Series	≥1800°C	Φ3-12 mm	W-type
1800T Series	≤1800°C	Φ3-12 mm	U-type

Voltage Settings for Small Furnaces (<100 kW)

Temperature Range	Voltage Setting
20-150°C	⅓ Operating Voltage
150-500°C	⅔ Operating Voltage
500°C to Target Temperature	Full Operating Voltage

Voltage Settings for Large Furnaces (100-500 kW)

Temperature Range	Voltage Setting
20-300°C	⅓ Operating Voltage
300-700°C	⅔ Operating Voltage
700°C to Target Temperature	Full Operating Voltage

Key Advantages

Exceptional oxidation resistance at high temperatures
Stable performance in oxidizing atmospheres
Long service life (up to 10,000 hours)
Customizable sizes and configurations
Suitable for dental furnaces and zirconia sintering applications

Applications

Dental zirconia sintering furnaces
High-temperature ceramic processing
Magnetic material heat treatment
Glass manufacturing and processing
Metallurgical heat treatment
Refractory material production

1800°C U-Shape MoSi2 Heating Element for Dental Furnace

Ordering Specifications

To proceed with your inquiry or order, please provide the following specifications:

D1: Hot Zone Diameter (mm)

D2: Cold End Diameter (mm)

Le: Length of Hot Zone (mm)

Lu: Length of Cold End (mm)

A: Shank Spacing / Center Distance (mm)

Please format your dimensions as follows:

D1/D2 * Le * Lu * A
(Example: 4/9 * 200 * 250 * 45mm)

Providing these exact parameters will ensure we can accurately meet your requirements.

Packaging & Delivery

Secure Packaging

Each MoSi2 heating element is carefully packaged in a custom-sized wooden case. The interior is lined with high-density foam to provide maximum shock absorption and prevent damage during transit. This ensures the brittle elements arrive in perfect condition.

Global Delivery

We offer reliable worldwide shipping options to get your order to you quickly and safely.
