1. Product Overview

This training platform is designed to demonstrate the structure and operation of an automotive charging system through hands-on learning. Built with real vehicle components, it allows students to observe how the alternator, battery, and voltage regulator work together. The system includes interactive features such as load simulation and fault diagnosis, making it ideal for vocational schools and technical training centers.

2. Key Features & Benefits

• Realistic Operation: A single-phase motor simulates engine rotation, driving the alternator to generate power while voltage and current meters display real-time data.
• Interactive Learning: Students can test the system using load lights and measure electrical signals via test terminals on the panel.
• Fault Simulation: A remote control allows instructors to set faults (e.g., broken circuits or relay failures) for troubleshooting practice.
• Durable Construction: The panel is made of high-quality aluminum-plastic board, and wiring follows automotive-grade standards for long-term reliability.

3. Technical Specifications & Applications

• Dimensions: 1200×600×1700mm (L×W×H)
• Power Supply: DC 12V (battery-powered)
• Motor: AC 220V, 2.2KW (simulates engine drive)
• Included Components: Alternator, battery, voltmeter, ammeter, load lights, and fault simulation module.

This platform helps students master charging system principles, perform electrical measurements, and develop diagnostic skills—essential for automotive technicians.
