Automotive Sensor Actuator Measurement Educational Equipment
Price:
Negotiatable
MOQ:
1
Delivery Time:
15-25Work Days
Brand:
Zhongcai
Product Description
Automotive Sensors & Actuators Training Platform
1. Product Overview
This integrated training system consolidates 16 critical automotive sensors and actuators onto a single demonstration panel. Designed for technical education, it enables hands-on experimentation with signal measurement, fault diagnosis, and operational principles of modern vehicle control systems.
2. Core Features
| Functionality | Technical Implementation |
|---|---|
| Interactive Simulations | • Motor-driven sensors (Crankshaft, ABS wheel speed) with adjustable signal disks • Airflow meter with variable-speed fan • 12+ manually adjustable sensors (O₂, throttle position, etc.) |
| Real-time Diagnostics | Test terminals for voltage/resistance/frequency measurement; color-coded UV-printed circuit diagrams |
| Robust Construction | 4mm fireproof panels, automotive-grade wiring, 220V-to-12V conversion, lockable casters |
3. Technical Specifications
- Dimensions: 1600×600×1700mm
- Power Input: AC 220V ±10% 50Hz
- Operating Voltage: DC 12V
- Frame Material: 60×40×3mm steel tubing
- Temperature Tolerance: -40°C to +50°C
Training Objectives: Sensor/actuator operational theory, signal voltage analysis (e.g., oxygen sensors, ABS wheel speed), and systematic fault troubleshooting.
