Forged Logging Tire Chains – Custom Heavy-Duty Traction Parts For Forestry Vehicles
Forged Logging Tire Chains – Custom Heavy-Duty Traction Parts for Forestry Vehicles
Product Overview :
Premium Forged Construction for Extreme Environments
Our forged logging tire chains are engineered to deliver maximum traction, durability, and load-bearing performance in the most demanding forestry, off-road, and heavy equipment applications. Manufactured using high-grade alloy steel and precision hot-forging techniques, these chains resist wear, deformation, and corrosion—ensuring long-lasting performance in mud, snow, rocky terrain, and harsh weather conditions.
Product parameters :
1. Basic Specifications
|
Parameter |
Specification |
|---|---|
|
Material |
High-carbon alloy steel (40Cr/42CrMo), optional stainless steel or galvanized coating |
|
Process |
Hot forging + precision machining (CNC) |
|
Hardness |
HRC 38-45 (customizable) |
|
Tensile Strength |
≥850 MPa (up to 1,200 MPa available) |
|
Surface Treatment |
Shot blasting, galvanization, or epoxy coating (anti-corrosion) |
2. Size & Dimensions
|
Type |
Specification |
|---|---|
|
Chain Link Thickness |
20mm, 25mm, 30mm, 40mm, 50mm (customizable) |
|
Chain Width |
50mm - 200mm (adjustable based on tire size) |
|
Chain Pitch |
50mm - 150mm (standard or custom patterns) |
|
Tire Compatibility |
Fits 16" - 54" forestry/off-road tires |
3. Performance & Load Capacity
|
Parameter |
Specification |
|---|---|
|
Static Load Capacity |
5 - 50 tons (depending on chain thickness) |
|
Dynamic Load Capacity |
3 - 30 tons (impact resistance) |
|
Operating Temperature |
-40°C to +200°C (special alloys available for extreme conditions) |
|
Abrasion Resistance |
High (tested in mud, rock, and snow conditions) |
Key Features & Benefits
✔ Ultra-Durable Forged Steel – Made from high-tensile alloy steel (40Cr/42CrMo) for superior strength and impact resistance.
✔ Customizable Designs – Available in 20mm–50mm thicknesses, with adjustable link patterns (e.g., square, twist, or diamond) for optimal grip.
✔ Corrosion-Resistant Options – Galvanized, powder-coated, or epoxy finishes for extended lifespan in wet/abrasive conditions.
✔ Heavy-Duty Load Capacity – Supports static loads up to 50 tons (varies by model), ideal for logging trucks, skidders, and forestry tractors.
✔ Easy Installation & Fit – Pre-tensioned and compatible with major tire brands (e.g., Michelin, Bridgestone, Goodyear) and custom forestry tires.
✔ Rigorous Quality Testing – Each batch undergoes ultrasonic (UT) and magnetic particle inspection (MPI) to ensure defect-free performance.
Applications
-
Forestry & Logging – Enhanced traction for skidders, forwarders, and heavy haulers.
-
Off-Road & Mining – Reliable grip for dump trucks, loaders, and utility vehicles.
-
Winter Operations – Superior ice/snow traction for plows and arctic logging equipment.
Why Choose Our Forged Logging Chains?
✅ OEM/ODM Support – Custom sizes, logos, and packaging available.
✅ Competitive Bulk Pricing – MOQ 50 pieces (samples negotiable).
✅ Fast Lead Times – 15–30 days production (ready stock for urgent orders).
✅ Global Certifications – Complies with ISO 9001, CE, and ASTM A668 standards.
