Custom Die Forged Parts Scraper Chains Precision Stainless / Carbon Steel Forgings
Custom Die-Forged Scraper Chains – Precision Stainless & Carbon Steel Forgings
Product Overview : Custom Die-Forged Scraper Chains
Material : High-grade Stainless Steel & Carbon Steel
Process : Precision Die Forging (Closed-Die/Hot Forging)
Applications : Conveyor systems, agricultural machinery, industrial scrapers, mining equipment, and heavy-duty material handling.
Key Features :
✅ Superior Strength – Forged microstructure enhances durability and load-bearing capacity.
✅ Wear & Corrosion Resistance – Stainless steel options for harsh environments (food, chemical, marine).
✅ Tight Tolerances – Precision forging ensures consistent dimensions (±0.1–0.3mm).
✅ Custom Designs – Tailored links, pitches, and attachments to fit OEM specifications.
✅ Cost-Effective – Reduced machining needs vs. traditional fabrication.
Technical Parameters: Custom Die-Forged Scraper Chains
| Parameter | Stainless Steel Chains | Carbon Steel Chains | Remarks |
|---|---|---|---|
| Material Grade | SS304, SS316, 17-4PH, etc. | AISI 1045, 4140, C45, etc. | Custom alloys available |
| Tensile Strength | ≥520 MPa | ≥600 MPa | Higher grades on request |
| Hardness (HRC) | 28–35 HRC | 35–45 HRC | Heat-treated options |
| Pitch Tolerance | ±0.2 mm | ±0.2 mm | Adjustable per design |
| Max. Chain Width | Up to 300 mm | Up to 300 mm | Wider sizes negotiable |
| Surface Finish | Polished, shot-blasted | Zinc-plated, black oxide | Anti-corrosion coatings |
| Operating Temp. | -50°C to +400°C | -20°C to +250°C | Material-dependent |
| Certifications | ISO 9001, ASTM A276, DIN 7648 | ISO 9001, ASTM A29 | ROHS/REACH compliant |
Notes :
Customization : All parameters (e.g., pitch, link shape, thickness) can be tailored to OEM requirements.
Testing : Includes 100% dimensional inspection, load testing, and material certification.
Packaging : Wooden crates or corrosion-proof wrapping for export.
