Carbon Steel Hot Forged Parts For Goal Fencing And Railings
High-Quality Hot-Forged Carbon Steel for Goal Fencing and Railings
Product Overview
Our hot-forged carbon steel components are engineered to deliver exceptional structural integrity, impact resistance, and long-term durability for goal fencing, railings, and other high-stress architectural and industrial applications.
Key Features
✅ Superior Material Quality – Made from high-grade carbon steel (AISI 1045/4140) for unmatched strength and fatigue resistance.
✅ Hot-Forged Construction – Precision-forged under high pressure for enhanced grain structure and toughness.
✅ Corrosion Protection – Available with hot-dip galvanizing (50-80µm), powder coating, or epoxy finishes for harsh environments.
✅ High Load-Bearing Capacity – Designed to withstand heavy impacts, bending forces, and dynamic loads.
✅ Customizable – Tailored dimensions, shapes, and finishes to meet project specifications.
Applications
✔ Sports & Stadium Infrastructure – Goal posts, fencing, and protective barriers.
✔ Industrial & Warehouse Railings – Heavy-duty guardrails and safety barriers.
✔ Architectural & Urban Design – Decorative yet robust railings for bridges, balconies, and public spaces.
✔ Transportation Safety – Highway guardrails, crash barriers, and bollards.
Product parameters
| Parameter | Description |
|---|---|
| Material | Hot-Forged Carbon Steel |
| Finish | Powder Coated / Galvanized |
| Dimensions | Customizable (e.g., height, width) |
| Weight | Varies by size (e.g., 15 kg/m) |
| Corrosion Resistance | Excellent |
| Load Capacity | Up to 500 kg per section |
| Installation Type | Bolted / Welded |
| Color Options | Black, Green, Custom Colors |
| Usage | Fencing, Railings, Decorative Elements |
| Certifications | ISO, ASTM |
Feel free to modify any parameters as needed!
Product application
- Sports Facilities: Ideal for goal posts and fencing in soccer, hockey, and other sports venues.
- Residential Fencing: Perfect for creating secure and decorative yard boundaries.
- Commercial Properties: Suitable for fencing around businesses, parks, and recreational areas.
- Balustrades and Handrails: Used for stairs and balconies, providing safety and style.
- Public Spaces: Great for park railings, playgrounds, and outdoor event areas.
- Artistic Installations: Can be used in custom designs for artistic fencing and railings.
- Security Barriers: Effective for creating secure perimeters in various environments.
FAQ
1. Material & Specifications
Q: What steel grades do you offer?
A: We primarily use AISI 1045 and 4140 carbon steel, known for their high strength and durability. Other grades are available upon request.
Q: What certifications do your products have?
A: Our steel complies with ASTM A668, EN 10025, and ISO 1461 standards. We also provide RoHS and REACH compliance documentation.
Q: What is the yield and tensile strength?
A:
-
Yield Strength: ≥ 355 MPa
-
Tensile Strength: 470–630 MPa
-
Impact Resistance: ≥ 27J (Charpy V-notch at -20°C)
2. Manufacturing & Customization
Q: What is hot forging, and why is it better?
A: Hot forging involves shaping steel at 1100–1250°C, resulting in superior grain structure, strength, and fatigue resistance compared to cold-formed alternatives.
Q: Can I request custom sizes or shapes?
A: Yes! We offer:
-
Custom diameters (30–150mm)
-
Wall thickness (5–20mm)
-
Special finishes (e.g., galvanized, powder-coated, or painted)
-
Laser-cut logos or patterns
Q: What tolerances do you maintain?
A: Standard: ±1.5mm, Precision: ±0.5mm (for machined surfaces).
3. Durability & Performance
Q: How corrosion-resistant is your steel?
A: With hot-dip galvanizing (50–80µm) or powder coating (60–120µm), our products withstand 500+ hours in salt spray tests.
Q: What is the expected lifespan?
A: Depending on the environment:
-
Galvanized: 20+ years (urban), 15+ years (coastal/industrial)
-
Powder-Coated: 15+ years (with proper maintenance)
Q: Can it withstand extreme weather?
A: Yes! Operational range: -40°C to +150°C. UV-resistant coatings are available.
4. Applications & Installation
Q: What are typical applications?
A:
-
Sports: Goal posts, stadium fencing
-
Industrial: Warehouse railings, safety barriers
-
Infrastructure: Bridge railings, highway guardrails
-
Architectural: Decorative railings, urban furniture
Q: How do I install these components?
A: We provide pre-drilled holes for bolts (M8–M20). Welding is also an option. Installation guides are available upon request.
5. Ordering & Logistics
Q: What is the MOQ?
A: 1 ton (standard items), but negotiable for large projects.
Q: What is the lead time?
A:
-
Standard orders: 15–30 days
-
Custom orders: 45–60 days
Q: How are products packaged?
A: VCI anti-rust paper + wooden crates for bulk shipments. Edge protection is included.
Q: Do you offer samples?
A: Yes! Samples are available for material verification (shipping costs may apply).
6. Quality Assurance
Q: How do you ensure quality?
A: Every batch undergoes:
-
Chemical composition analysis
-
Mechanical testing (tensile, hardness, impact)
-
Coating thickness checks
Q: Can I get test reports?
A: Yes! We provide mill test certificates (EN 10204 3.1) and third-party inspection reports upon request.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
