PHR-100 PHR-200 Magnetic Rockwell Hardness Tester Rockwell And Brinell Hardness
PHR-100 PHR-200 Magnetic Rockwell Hardness Tester Magnetic Brinell Rockwell Hardness Tester
Fix Rockwell test head to the surface of iron and steel parts to test the hardness by applying magnetic force. Follow Rockwell hardness test method completely and the test condition complies with standard of ISO 6508 and ASTM E 18. The magnetic Rockwell hardness tester is mainly applied in on-site quick test body hardness of steel parts. Test hardness of steel plate, pipe, axis, mould, huge forgings and huge and medium-size heat treatment parts if surface available. Test hardness of weld joint in boiler, pressure vessels, and pressure pipes. Replace low accurate and reliable Leeb hardness testers.
| Initial Test Force for Rockwell: | 10kgf |
|---|---|
| Total Test Force: | 60kgf, 100kgf, 150kgf |
| Test head: | 120°diamond indenter, 1.588mm carbide ball indenter |
| Indication Error: | Comply with ISO 6508 and ASTM E 18 |
| Testing Resolution: | 0.5 HR |
| Weight: | 4.7 kg |
| Surface: | Flat : Area ≥ 180 mm x 60 mm |
| Thickness : | ≥ 5 mm |
| Cylinder: | Diameter ≥ 60 mm Length ≥ 200 mm |
