1064nm Compact Raman Spectroscopy Analyzer Handheld Portable Raman Spectrometer
| Attribute | Value |
|---|---|
| Laser wavelength | 1064nm |
| Spectral Bandwidth | 0.5 cm-1 |
| Wavelength repeatabilityInterface | 0.1 cm-1 |
| Function | Qualitative identification of compounds |
| Response speed | ~15s |
| Survivability | IP68 |
JINSP RS1500DI can perform 100% package-by-package inspection of both raw materials and packaging materials. It can quickly identify raw materials in warehouses, material preparation rooms, production workshops, etc., helping pharmaceutical companies to quickly release materials.
When analyzing excipients, fluorescence often interferes with proper chemical identification and analysis. The JINSP RS1500DI uses a 1064 nm laser to effectively reduce fluorescence interference.
Furthermore, RS1500DI is compliant with relevant regulations such as FDA 21 CFR Part11 and GMP.
| Item | Description |
|---|---|
| Laser | 1064nm |
| Size | 176mm*87mm*33mm |
| Weight | 730g |
| Connection | Wi-Fi, 4G, Bluetooth, Micro-USB |
| Operation | 5" Touch Screen, big button, intuitive man-machine interface operation |
| Power Supply | Rechargeable lithium battery, 4-6h |
| Detection Range | Chemical raw materials; Pharmaceutical excipients; Packing materials; Biochemical raw materials; Pigment excipients |
| Result | Name, Property, Spectrum, MSDS, Result-report |
- Quick response: Identification can be completed within a few seconds.
- Non-destructive identification: Direct detection through glass, woven bags, plastic and other packaging.
- Compact and lightweight: Can be moved flexibly in warehouses, material preparation rooms, and production workshops.
- Real-time sampling: No need for sampling, simple and safe.
- Identification accuracy: Advanced machine learning algorithm supports accurate recognition with strong specificity.
- Chemical raw materials: aspirin, folic acid, nicotinamide, etc.
- Pharmaceutical excipients: salts, alkalis, sugars, esters, alcohols, phenols, etc.
- Packaging materials: polyethylene, polypropylene, polycarbonate, ethylene-vinyl acetate copolymer, etc.
- Biochemical raw materials: amino acids and their derivatives, enzymes and coenzymes, proteins, etc.
- Pigment excipients: carmine, carotene, curcumin chlorophyll, etc.
- Other polymer excipients: gelatin, microcrystalline cellulose, etc.
JINSP Company Limited, abbreviated as "JINSP", is a professional supplier with over 17 years of experience in spectral detection technology products, including Raman, FT-IR, LIBS technologies, etc. After 17 years of technology accumulation, the company's core key technologies have reached the international leading position, with cumulative patent applications exceeding 200.
JINSP offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security, and customs. Products are available nationwide and are exported to over 30 countries, with cumulative sales exceeding 3,000 units.
Benefiting from 30+ R&D engineers, including 4 Ph.D., JINSP is deeply rooted in the field of personalized product customization, and is committed to meeting the diverse and unique needs of customers with excellent professional technology and innovative design capabilities.
A: The brand name of the pharmaceutical spectrometer is JINSP.
A: The model number of the pharmaceutical spectrometer is RS1000DI.
A: Yes, It is certified with CE.
