JINSP SR100Q Advanced CCD Fiber Optic Spectrometer with High Quantum Efficiency for Ultraviolet Band and TE Cooling
92% High Quantum Efficiency CCD Modular Fiber Optic Spectrometer
Designed for researchers and engineers, the JINSP SR100Q Spectrometer combines high-resolution optics with cutting-edge sensor technology. The built-in Hamamatsu CCD with TE cooling minimizes thermal noise, enabling precise detection of weak light signals. With peak QE reaching 92%, users can trust the SR100Q for accurate spectral data across UV, VIS, and NIR ranges.
This spectrometer is particularly well-suited for laser spectral measurement, allowing real-time tracking of wavelength, intensity, FWHM, and multi-peak analysis. It also supports film thickness measurement via reflective or absorptive spectral methods, providing non-destructive testing solutions for semiconductors and optical coatings.
With its robust FPGA processing and intuitive operation, the SR100Q is a reliable tool for advancing scientific and industrial applications.
Product Parameters:
| Detector | Chip Type | Back-illuminated TE-cooled Hamamatsu S7031 |
| Effective Pixel | 1024*122 | |
| Pixel Size | 24*24μm | |
| Sensing Area | 24.576*2.928mm | |
| Optical Parameters |
Optical Design | F/4 cross-type |
| Numerical Aperture | 0.13 | |
| Focal Length | 100mm | |
| Entrance Slit Width | 10μm,25μm,50μm,100μm,200μm (customizable) |
|
| Fiber Interface | SMA905,free space | |
| Electrical Parameters |
Integration Time | 8ms-3600s |
| Data Output Interface | USB3.0,RS232,RS485,20pin connector | |
| ADC Bit Depth | 16-bit | |
| Power Supply | 5V | |
| Operating Current | <3.5A | |
| Physical Parameters |
Operating Temperature | 10℃~40℃ |
| Storage Temperature | -20℃~60℃ | |
| Operating Humidity | <90%RH (no condensation) | |
| Dimensions | 180mm*120mm*50mm | |
| Weight | 1.2kg |
List of Product Models:
| Model | Spectral Range(nm) | Resolution(nm) | Slit(μm) |
| SR100Q-G21 SR100Q-G22 |
200~950 350~1100 |
6.8 | 200 |
| 2.2 | 50 | ||
| 1.5 | 25 | ||
| 1.0 | 10 | ||
| SR100Q-G23 SR100Q-G24 |
200~775 350~925 |
1.6 | 50 |
| 1.0 | 25 | ||
| 0.7 | 10 | ||
| SR100Q-G25 | 532~690(4400cm-1*)* | 13cm-1 | 50 |
| SR100Q-G26 | 638~800(3200cm-1)* | 10cm-1 | 25 |
| SR100Q-G27 | 785~1050(3200cm-1)* | 11cm-1 | 50 |
Technical Characteristics:
- High quantum efficiency, 92%peak@650nm, 83%@232nm
- High SNR: Ultra-low dark noise under long integration time, SNR is as high as 1000:1
- Noise-free clear processing of weak signal in long exposure, strong adaption to environment
- Low-noise and high-speed circuit: USB3.0
Typical Applications:
- Detect absorption, transmittance and reflection Spectrum
- Light source and laser wavelength characterization
- OEM product module: Fluorescence spectrum, Raman spectrum, etc.
Company Instroductions:
JINSP – Secure, Certified Spectral Detection Solutions
Trusted by global security and industrial sectors, JINSP Company Limited offers 17 years of expertise in Raman, FT-IR, and LIBS technologies. Our Beijing HQ and Jiangsu plant produce 200+ patented systems, rigorously tested for ECAC, CE, IP Level, and Public Security compliance. When accuracy and certification matter, JINSP delivers.
FAQ
Q1:This is the first time I use,is it easy to operate?
A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.
Q2:Can your offer a operation traning?
A2:Your technicians can come to our factory for a training. Jinsp engineers can go to your place for local support
( installation , training, debugging, maintenance ).
Q3:What's your website?
A3:You can visit:www.jinsptech.com
Q4:What about your quality assurance?
A4:We have a quality inspection team. All goods will go through quality inspection before shipment. We can send you pictures for inspection.
