Standard Online Raman Analyzer 100VAC For Petrochemical Fluorine
Raman Spectroscopy Multi-gas Analyzer for Simultaneous Online Analysis
JINSP® RS2600 multi-gas analyzer is based on Raman spectroscopy and can detect all gases except noble gases,enabling simultaneous online analysis of multiple gases including:
- Petrochemical industry: alkane, alkene and alkyne gases such as CH4, C2H6, C3H8, C2H4, etc.
- Fluorine chemical industry: corrosive gases such as F2, BF3, PF5, Cl2, HCl, HF, etc.
- Metallurgical industry: N2, H2, O2, CO2, CO, etc.
Technical Specifications:
|
Components |
N2, H2, O2, CO, CO2, H2S, CmHn, etc. |
|
Analysis time |
2 seconds |
|
Measurement uncertainty |
≤0.2% |
|
Laser excitation wavelength |
532 ± 0.5 nm |
|
Spectral coverage |
200 ~ 4200 cm-1 |
|
Spectral resolution |
≤8 cm-1 at full spectral range |
|
Air circuit interface |
6 mm standard tube fitting (3 mm, 1/8’’, and 1/4’’ are optional) |
|
Input voltage |
100~240 VAC,50~60 Hz |
|
Sample gas temperature |
-50 ~ 40 ºC |
|
Sample gas pressure |
＜1.0 MPa |
|
Unit dimensions |
485 mm (Width) × 350 mm (Height) × 600 mm (Depth) |
|
Weight |
40 kg |
Technical highlights:
Non-destructive gas analysis is a technique that allows for the examination of gas samples without altering their composition or structure. This method is particularly useful for analyzing analytes such as homonuclear diatomic gases, which include fluorine (F2), chlorine (Cl2), and others. Additionally, it is effective for isotopic gases like hydrogen (H2), deuterium (D2), and tritium (T2). These gases can be studied in their natural state, preserving their integrity for further analysis or use.
Applications:
1.Monitoring of F2, N2, HF and other components in the fluorination process
2.Quantitative analysis of different Elements in Petrochemical Natural Gas
Effective identification and quantification of various components in natural gas mixtures within 2 seconds
- Quantitative model of multiple standard curves,combined with the chemometric method, establishes the relationship between the spectral signal and the content of multi-component substances.
- Changes in sample gas pressure and test conditions do not affect the accuracy of quantitative results.
Company Introduction:
JINSP Company Limited originates from Tsinghua University and has 17 years of experiences in developing spectroscopic technology.As a leading supplier of spectroscopic technology,JINSP Technology offers over twenty spectroscopic products across various fields, including pharmaceutical and chemical industries, public security and customs.
FAQ:
Q1:This is the first time I use,is it easy to operate?
A1:We will send you manual and guide vedio in English,it can teach you how to operate the spectrometer.Also our technicians will offer professional tecnical opearation meetings.
Q2:Can you offer a operation training?
A2:Your technicians can come to our factory for a training. Jinsp technical engineers can go to your place for local support.
( installation, training,debugging,maintenance )
Q3:How to receive a best price in the shortest time?
A3:When you send us an inquiry,please kindly offer details with wavelength,detector,effective pixels,focal length and so on.We will send you quotation with details soon to your email.
Q4:If the spectrometer has problem in my place,how could I do?
A4:The spectrometer has one year warranty.If it breaks down,our technician will figure out what the problem maybe,according to client's feedback.We can repair for free within one year warranty.
