High Precision Compact Auto Level Equipment With Accessories 32x 24x Magnification
Price:
$80-6000
MOQ:
1
Delivery Time:
10-30days
Brand:
CETU
Product Description
High Precision Foif Dsz2 Auto Level with Accessories The Perfect Combination of Precision and Affordability
1. Compensator check button
2. Sealed and dustproof, easy to operate
3. Compact structure and beautiful appearance
4. A trim micrometer can be added, which can be used for national secondary leveling and settlement observation
5. Good temperature compensation performance
| Model | DSZ2 | DSZ3 | |
| Standard deviation of 1KM double run leveling | ≤±1.0mm | ≤±2.0mm | |
| Telescope | Image | Erect | |
| Magnification | 32 × | 24 × | |
| Clear Objective aperture | 40mm | 36mm | |
| Shortest focusing distance | 1.6m | 0.7m | |
| Stadia ratio | 100 | ||
| Stadia constant | 0 | ||
| Compensator | Working range | ±14′ | |
| Setting accuracy | ≤±0.3″ | ≤±0.5″ | |
| Setting time | ≤2S | ||
| Sensitivity of circular level per 2mm | 8′/2mm | ||
| Graduation interval of horizontal circle | 1 ° / DIV | ||
| Working temperature | -30°C-+50°C | ||
| Weight | 2.5kg | 2.0kg | |
